MENU SCREEN

Function items

Squelch/ATT Select
Function > Squelch/ATT Select
Select the function that varies according to the [SQL]
control position.
• OFF: Both the S-Meter Squelch and
Attenuator are disabled.
• S-Meter Squelch: The S-Meter Squelch activates
and adjusts the squelch level
when [SQL] is set between 12
o'clock and the fully clockwise
position.
• ATT: The Attenuator is enabled and
adjusts the attenuator level when
[SQL] is set between 12 o'clock
and the fully clockwise position.
Squelch Delay
Function > Squelch Delay
Set the squelch delay to short or long to prevent
repeated opening and closing of the squelch when
receiving the same signal.
• Short: Shortens the time until the squelch opens.
• Long: Lengthens the time until the squelch opens.
Fan Control
Function > Fan Control
Select the cooling fan control between Slow, Mid, Fast
and Auto.
• Slow: The fan rotates slow.
• Mid: The fan rotates at mid speed.
• Fast: The fan rotates fast.
• Auto: The fan automatically turns ON during
transmission or when the internal temperature
of the transceiver exceeds the preset value. It
remains ON until the temperature drops below
the value.
Dial Speed-UP
Function > Dial Speed-UP
Turn the dial speed acceleration ON or OFF.
The acceleration automatically speeds up the tuning
dial speed when you rapidly rotate [DIAL].
• OFF: Turns OFF the function.
• ON: Turns ON the function.
(Default: S-Meter Squelch)
(Default: Short)
(Default: Auto)
(Default: ON)
Auto Repeater
Function > Auto Repeater
The Auto repeater function automatically turns the
duplex operation and tone encoder* ON or OFF. The
offset and repeater tone* are not changed by the
auto repeater function. Reset these setting values, if
necessary.
L This item is displayed only in the USA version
transceiver.
• OFF:
• ON (DUP):
• ON (DUP, TONE): Turns ON the duplex operation
* The tone encoder will not be turned ON in the DV mode.
Remote MIC Key
Function > Remote MIC Key
The function assignments for [F-1] and [F-2] keys on
the supplied HM-207S
can be changed.
)
control
See pages 9-58 ~ 9-59 for the assignable key
functions.
• During RX/Standby: The assigned key function is
• During TX:
Up/Down MIC Key
Function > Up/Down MIC Key
The function assignments for the [UP] and [DN] keys
on the optional HM-154
(
hand microphone
See pages 9-58 ~ 9-59 for the assignable key
functions.
• During RX/Standby: The assigned key function is
• During TX:
9-57
(Default: ON (DUP))
Turns OFF the function.
Turns ON the duplex operation
only. (Default)
and tone encoder*.
(
hand microphone remote
enabled while receiving or in
standby.
The assigned key function is
enabled during transmission.
or HM-232
hand microphone
can be changed.
)
simple
enabled while receiving or in
standby.
The assigned key function is
enabled during transmission.
-
