Symbols and Conventions

Symbols used in this manual:
NB!:
Indicates something to be noted by the reader.
Indicates a general warning.
Indicates a high-voltage warning.
Indicates default setting.
*
Conventions
The information in this manual follows the system and uses the typographical features described below to
the greatest extent possible:
Menus and Functions
Menus and functions are printed italics, for example: Controller → Parameters.
Commands and Parameters
Commands and parameter names are written in capitals, for example: AXEND and KPROP; Parameters are
printed in italics, for example: Proportional factor.
Parameter Options
Values for use to select the parameter options are written in brackets, e.g. [3].
Keys
The names of keys and function keys are printed in brackets, for example the control key [Cntl] key, or just
[Cntl], the [Esc] key or the [F1] key.

Abbreviations

Automatic Motor Adaptation
Control word
Direct Current
Digital Signal Processor
Frequency Converter
Local Control Panel
Least significant bit
Main actual value
Motion Control Option
Motion Control Tool
Minute
Most significant bit
Main Reference
Master Unit
Digital output switching to high side.
__ How to Read this MCO 305 Design Guide __
AMA
CTW
DC
DSP
FC
LCP
LSB
MAV
MCO
MCT
min
MSB
MRV
MU
NPN
®
MG.33.L5.02 – VLT is a registered Danfoss trademark
Switch normally closed
Switch normally open
Parameter
Position Control Loop
Digital output switching to low side.
Pulses per Revolution
Quad-counts
Reference
Revolutions per Minute
Second, Millisecond
Sample time
Status word
User Unit
Volts
nc
no
par.
PID
PNP
PPR
qc
REF
RPM
s, ms
st
STW
UU
V
5
