Par. No. Parameter name
#
33-32 SYNCFFVEL
33-33 SYNCVFLIMIT
33-4* Limit Handling
33-40 ENDSWMOD
33-41 NEGLIMIT
33-42 POSLIMIT
33-43 SWNEGLIMACT
33-44 SWPOSLIMACT
33-45 TESTTIM
33-46 TESTVAL
33-47 TESTWIN
33-5* I/O Configuration
33-50 I_FUNCTION_1
33-51 I_FUNCTION_2
33-52 I_FUNCTION_3
33-53 I_FUNCTION_4
33-54 I_FUNCTION_5
33-55 I_FUNCTION_6
33-56 I_FUNCTION_7
33-57 I_FUNCTION_8
33-58 I_FUNCTION_9
33-59 I_FUNCTION_10
33-60 IOMODE
33-61 I_FUNCTION_11
33-62 I_FUNCTION_12
33-63 O_FUNCTION_1
default setting
__ Parameter Reference __
Parameter description
Feed Forward Speed
Adaptation
Velocity Filter Window
Behavior at End Limit
Switch
Negative Software End
Limit
Positive Software End Limit
Negative Software End
Limit Active
Positive Software End Limit
Active
Time in Target Window
Target Window Limit Value
Size of Target Window
Terminal X57/1 Digital
Input
Terminal X57/2 Digital
Input
Terminal X57/3 Digital
Input
Terminal X57/4 Digital
Input
Terminal X57/5 Digital
Input
Terminal X57/6 Digital
Input
Terminal X57/7 Digital
Input
Terminal X57/8 Digital
Input
Terminal X57/9 Digital
Input
Terminal X57/10 Digital
Input
Terminal X59/1 and X59/2
Mode
Terminal X57/11 Digital
Input
Terminal X57/12 Digital
Input
Terminal X59/1 Digital
Output
[ ] value for use in communication via serial communication port
®
MG.33.L5.02 – VLT is a registered Danfoss trademark
Default Changes
setting during
operation
0 TRUE
0 qc TRUE
[0] Call error TRUE
handler
-500000 qc TRUE
500000 qc TRUE
[0] Inactive TRUE
[0] Inactive TRUE
0 ms TRUE
1 qc TRUE
0 qc TRUE
[0] no function TRUE
[0] no function TRUE
[0] no function TRUE
[0] no function TRUE
[0] no function TRUE
[0] no function TRUE
[0] no function TRUE
[0] no function TRUE
[0] no function TRUE
[0] no function TRUE
[0] Output 'FALSE'
[0] no function TRUE
[0] no function TRUE
[0] no function TRUE
4-set-up Conver- Type
sion
index
2 set-ups Uint32
2 set-ups Uint32
2 set-ups Uint8
2 set-ups Int32
2 set-ups Int32
2 set-ups Uint8
2 set-ups Uint8
2 set-ups Uint8
2 set-ups Uint16
2 set-ups Uint16
2 set-ups Uint8
2 set-ups Uint8
2 set-ups Uint8
2 set-ups Uint8
2 set-ups Uint8
2 set-ups Uint8
2 set-ups Uint8
2 set-ups Uint8
2 set-ups Uint8
2 set-ups Uint8
2 set-ups Uint8
2 set-ups Uint8
2 set-ups Uint8
2 set-ups Uint8
