MCO 305 Design Guide
Interrupt Functions
Command Description
DISABLE .. locks the execution of interrupts
ENABLE .. enables locked interrupts
ON CANINPUT id calls up a subprogram when a CAN
GOSUB telegram type 'id' arrives
ON CANMSG verifies arrival of a buffered CAN
GOSUB message
ON COMBIT .. call up a subprogram when Bit n of the
GOSUB communication buffer is set
ON DELETE .. deletes a position interrupt: ON posint
GOSUB GOSUB
ON ERROR calls subroutine in the event of an error
GOSUB
ON INT .. GOSUB calls subroutine depending on input
signal
ON KEYPRESSED interrupts when a LCP key is pressed or
GOSUB released
ON PARAM .. calls up a subprogram when a
GOSUB parameter is altered
ON PERIOD calls subroutine at regular intervals
GOSUB
ON posint .. calls up a subprogram when a position
GOSUB interrupt occurs:
ON APOS = when the slave position xxx
is passed
ON IPOS = distance between the last
marker position and the actual
position
ON MAPOS = when the master position
xxx [qc] is passed
ON MCPOS = when the master position
xxx [MU] is passed
ON MIPOS = distance between two
markers is reached.
180
__ How to Program __
®
MG.33.L5.02 – VLT is a registered Danfoss trademark
Syntax Parameter
DISABLE inttyp inttyp = INT, COMBIT, ...
ENABLE inttyp inttyp = INT, COMBIT, ...
ON CANINPUT id id = 0
GOSUB name
name = subroutine
ON CANMSG name = name of the subroutine
GOSUB name
ON COMBIT n n = bit n of communication
GOSUB name buffer
name = subprogram
ON DELETE pos pos = value
GOSUB name
name = subprogram name
ON ERROR GOSUB name = subprogram name
name
ON INT n GOSUB n = input to be monitored
name
name = subprogram name
ON KEYPRESSED name = subprogram name
GOSUB name
ON PARAM n n = parameter number
GOSUB name
name = subprogram name
ON PERIOD n n =
GOSUB name n > 20 ms (time for re-call)
n = 0 (switch off function)
name = subprogram name
ON sign postype sign=
position GOSUB + = rising edge or when the
name position is passed in positive
direction
– = falling edge or when the
position is passed in negative
direction
postype = APOS,IPOS, MAPOS
MCPOS, MIPOS
position = depending on the
command in user units [UU],
or master user units [MU],
or curve units [CU]
name = subprogram name
