MCO 305 Design Guide
__ APOSS Tools __
Stand-alone application
The Array Editor can be started stand-alone by adding either an argument to the Windows command line.
"/a" will start the Array Editor in User mode and
"/ae" will start the Array Editor in Expert mode.
In stand-alone application, the Array Editor will always start without a controller being connected and
without an array definition file being loaded. The user must explicitly connect to a controller and explicitly
load an array definition file.
Array Editor List
Controller arrays and parameters are displayed in a list similar to that shown below.
One or more rows in the list can be selected using any of the normal Windows list selection methods:
Clicking, [Shift]-clicking, or [Ctrl]-clicking.
Values can be edited (as far as allowed) by double-clicking on them.
Values that have been changed by the user will be displayed using a bold font. Values that are invalid for
any reason will be displayed with a red background. If the user pauses the mouse over an invalid value,
then a popup window will display a message describing the error.
