Field
802.3x Pause Frames
Received
Unacceptable Frame Type
Multicast Tree Viable Discards The number of frames discarded when a lookup in the multicast tree for a
Reserved Address Discards
Broadcast Storm Recovery
CFI Discards
Upstream Threshold
Packets Transmitted Octets
Total Packets Transmitted
(Octets)
Packets Transmitted 64
Octets
Packets Transmitted 65-127
Octets
Packets Transmitted 128-255
Octets
Packets Transmitted 256-511
Octets
Packets Transmitted 512-
1023 Octets
Packets Transmitted 1024-
1518 Octets
Maximum Frame Size
Packets Transmitted Successfully
Total Packets Transmitted
Successfully
D-Link
Oct. 2015
Table 72: Detailed Port Statistics Fields (Cont.)
Description
A count of MAC Control frames received on this interface with an opcode
indicating the PAUSE operation. This counter does not increment when the
interface is operating in half-duplex mode.
The number of frames discarded from this port due to being an unacceptable
frame type.
VLAN occurs while that tree is being modified.
The number of frames discarded that are destined to an IEEE 802.1 reserved
address and are not supported by the system.
The number of frames discarded that are destined for FF:FF:FF:FF:FF:FF when
Broadcast Storm Recovery is enabled.
The number of frames discarded that have CFI bit set and the addresses in RIF
are in non-canonical format.
The number of frames discarded due to lack of cell descriptors available for
that packet's priority level.
The total number of octets of data (including those in bad packets)
transmitted on the network (excluding framing bits but including FCS octets).
This object can be used as a reasonable estimate of ethernet utilization. If
greater precision is desired, the etherStatsPkts and etherStatsOctets objects
should be sampled before and after a common interval.
The total number of packets (including bad packets) received that were 64
octets in length (excluding framing bits but including FCS octets).
The total number of packets (including bad packets) received that were
between 65 and 127 octets in length inclusive (excluding framing bits but
including FCS octets).
The total number of packets (including bad packets) received that were
between 128 and 255 octets in length inclusive (excluding framing bits but
including FCS octets).
The total number of packets (including bad packets) received that were
between 256 and 511 octets in length inclusive (excluding framing bits but
including FCS octets).
The total number of packets (including bad packets) received that were
between 512 and 1023 octets in length inclusive (excluding framing bits but
including FCS octets).
The total number of packets (including bad packets) received that were
between 1024 and 1518 octets in length inclusive (excluding framing bits but
including FCS octets).
The maximum ethernet frame size the interface supports or is configured,
including ethernet header, CRC, and payload. (1518 to 9216). The default
maximum frame size is 1518.
The number of frames that have been transmitted by this port to its segment.
