D-Link DWL-6600AP Specifications

Unified n concurrent dual-band poe access point
Hide thumbs


Product Highlights
Enterprise Class Concurrent Dual Band Wireless Radio
Supports 2x2 MIMO 2.4/5Ghz 802.11a/b/g/n with
throughput speeds up to 300Mbps.
Flexible Housing Design
Embedded antennas with external antenna option
and plenum rated housing for non-intrusive and safe
deployment in any indoor application.
Wireless Management Support
Works with DWC-1000 Wireless Controller and
DWS-3160/4026 Unified Wireless Switch for larger AP
installations that require centralized configuration
and management.
Unified N Concurrent Dual-band PoE Access Point
Ideal for Business
• Blazing wireless performance of up to 300 Mbps
network throughput
• Configuration Replicating Clusters reduce configuration
• Up to 32 virtual access points may be created from a
single device
• Automatic load-balancing among neighboring access points
• Flexible QoS with WMM
Trusted Security
• WPA/WPA2 Personal
• WPA/WPA2 Enterprise
• WEP Encryption
• 802.1X User authentication
• MAC address filtering
• Rogue AP detection
Convenient Installation
• Can be easily mounted on a wall or ceiling
• 802.3af Power Over Ethernet enables installation in
installation in hard-to-reach locations
• Mounting brackets are included
The DWL-6600AP Unified N Dual-band PoE Access Point is a best-in-class indoor access
point designed specifically for business-class environments. With high data transmission
speeds and access point load balancing, the DWL-6600AP offers high-quality and reliable
wireless service. Versatile and powerful, the DWL-6600AP can be flexibly deployed as a
standalone wireless access point or as a managed access point controlled by a D-Link®
Unified Wireless Switch or Wireless Controller. Businesses can start with standalone mode
deployment, then migrate to a centrally managed system anytime later.
Enhanced Performance
The DWL-6600AP delivers reliable wireless performance with maximum wireless signal
rates of up to 300 Mbps in either the 2.4 GHz or 5 GHz mode. Support for Wi-Fi Multimedia™
(WMM) Quality of Service features makes the DWL-6600AP an ideal access point for audio,
video, and voice application. In addition, the load balancing feature ensures maximum
performance and best service quality in the wireless environment
Configuration Replicating Clusters
For small businesses that need to deploy multiple access points (APs) but lack the resources
to tackle the complicated task of network management, the DWL-6600AP's clustering
feature offers the ideal solution. When a small number of DWL-6600APs is deployed on the
network, they may be configured to form a cluster. Once the administrator is through with
configuring one access point, the same configuration can then be applied to all remaining
APs that are members of that cluster. Up to 16 APs may be used to form a cluster.



  Related Manuals for D-Link DWL-6600AP

  Summary of Contents for D-Link DWL-6600AP

  • Page 1 300 Mbps in either the 2.4 GHz or 5 GHz mode. Support for Wi-Fi Multimedia™ • WEP Encryption (WMM) Quality of Service features makes the DWL-6600AP an ideal access point for audio, • 802.1X User authentication video, and voice application.
  • Page 2: Quality Of Service

    The DWL-6600AP supports the latest standards in Wi-Fi security, including With an embedded antenna and simple styled exterior, the DWL-6600AP can WEP, WPA, WPA2, and 802.1X. In addition, the DWL-6600AP supports up to 16 be installed on a wall or ceiling and blends in with most interior decorations virtual access points (VAP) per radio, for a total of 32 VAPs, which allows the in an office.
  • Page 3 • Local Storage Configuration • AP Load Balancing Setup Managed Mode • Centralized Management • Rogue AP Detection (Managed by D-Link Wireless Switch/ • Centralized Firmware Dispatch • Rogue AP Mitigation Wireless Controller) • Visualized AP Management Tool • WIDS •...
  • Page 4: For More Information

    U.S.A. | 17595 Mt. Herrmann Street | Fountain Valley, CA 92708 | 800.326.1688 | Canada | 2525 Meadowvale Blvd | Mississauga, ON L5N 5S2 | 800.361.5265 | ©2012 D-Link Corporation/D-Link Systems, Inc. All rights reserved. D-Link, the D-Link logo, and D-ViewCam are trademarks or registered trademarks of D-Link Corporation or its subsidiaries in the United States and/or other countries. Other trademarks or registered trademarks are the property of their respective owners.
