D-Link UWS User Manual
Field
Packets Received > 1522
Octets
Packets Received Successfully
Total Packets Received
Without Errors
Unicast Packets Received
Multicast Packets Received
Broadcast Packets Received
Packets Received with MAC Errors
Total Packets Received with
MAC Errors
Jabbers Received
Fragments Received
Undersize Received
Alignment Errors
Rx FCS Errors
Overruns
Total Ignored Frames
Total Deferred Frames
Received Packets Not Forwarded
Total Received Packets Not
Forwarded
Local Traffic Frames
D-Link
Oct. 2015
Table 72: Detailed Port Statistics Fields (Cont.)
Description
The total number of packets received that were longer than 1522 octets
(excluding framing bits, but including FCS octets) and were otherwise well
formed.
The total number of packets received that were without errors.
The number of subnetwork-unicast packets delivered to a higher-layer
protocol.
The total number of good packets received that were directed to a multicast
address. Note that this number does not include packets directed to the
broadcast address.
The total number of good packets received that were directed to the
broadcast address. Note that this does not include multicast packets.
The total number of inbound packets that contained errors preventing them
from being deliverable to a higher-layer protocol.
The total number of packets received that were longer than 1518 octets
(excluding framing bits, but including FCS octets), and had either a bad Frame
Check Sequence (FCS) with an integral number of octets (FCS Error) or a bad
FCS with a non-integral number of octets (Alignment Error). Note that this
definition of jabber is different than the definition in IEEE-802.3 section
8.2.1.5 (10BASE5) and section 10.3.1.4 (10BASE2). These documents define
jabber as the condition where any packet exceeds 20 ms. The allowed range
to detect jabber is between 20 ms and 150 ms.
The total number of packets received that were less than 64 octets in length
with ERROR CRC (excluding framing bits but including FCS octets).
The total number of packets received that were less than 64 octets in length
with GOOD CRC (excluding framing bits but including FCS octets).
The total number of packets received that had a length (excluding framing
bits, but including FCS octets) of between 64 and 1518 octets, inclusive, but
had a bad Frame Check Sequence (FCS) with a non-integral number of octets.
The total number of packets received that had a length (excluding framing
bits, but including FCS octets) of between 64 and 1518 octets, inclusive, but
had a bad Frame Check Sequence (FCS) with an integral number of octets
The total number of frames discarded as this port was overloaded with
incoming packets, and could not keep up with the inflow.
The total number of dropped packets including those that were aborted.
The total number of frames that could not be transmitted after multiple
attempts because they encountered collisions.
A count of valid frames received which were discarded (i.e., filtered) by the
forwarding process.
The total number of frames dropped in the forwarding process because the
destination address was located off of this port.
Viewing System Statistics
Unified Wired and Wireless Access System
Page 164
