Chapter 15: Maintaining Your Library
Maintenance Actions
530
2 You can display library data using either the Select Filter options or
clicking on a particular module in the Select Module area. In
addition, there is a button toward the bottom of the screen called
Partition View. If you click on this button, the displayed
information is color-coded according to partition so it is easy to see
where all the elements in each partitions are located.
• In the Select Filter area, you can search for and display specific
criteria according to device type and location coordinates, or by
Media ID.
• Select the DeviceType filter, and then from the Type drop-
down list, click the appropriate device type: Storage, IE (I/E
Station), or Drive. Click Show.
The Control Module dialog box displays a graphical view of
the library elements according to your Type filter choices.
• To search for a specific cartridge according to the cartridge's
barcode, select the Media ID filter, type the barcode in the
Media ID field, and then click Show.
The Module dialog box displays the specific cartridge
highlighted in red within the module where it is located.
• To search for a specific cartridge according to the element
address, select the Element Address filter, type the element
address in the field, then click Show. You must be in
partition view to filter using the Element Address.
• In the Select Module area, you can select a specific module in
your library to view. On a multi-module library, all modules are
represented.
• In the Select Module area, click on the module you want to
view. The Module dialog box displays the current
configuration of Rack one and Rack two (Door - Inside view)
according to the module you chose.
Note: The Rack two (Door - Inside view) view is MIRROR
image of the outside view, so I/E station B is on the left,
and I/E station A is on the right.
• If you click the Partition View button, the graphical display
opens at the left-most module. The upper portion of the screen
displays a legend showing which colors represent each
