Chapter 15: Maintaining Your Library
Monitoring the Library
Element
IE Station #
Magazine #
Media ID
Slot Type
Partition Name
504
The following table describes the elements on the I/E Station Status
dialog box.
Description
All single door I/E stations are numbered starting with 1 at the control
module
All double door I/E stations are numbered with a number and a letter - for
example 2A and 2B--the frame number (1-16), with A as the left I/E
station and B the right.
The number of the I/E station magazine (numbered from top to bottom in
the I/E station).
The cartridge barcode or the word EMPTY.
The media type (for example, LTO).
The name of the partition to which the I/E station is assigned.
