Quantum Scalar i6000 User's Guide
Horizontal Alignments
The Horizontal Alignments graphical report shows the results for tests
of horizontal alignment of tape magazines on the drive-side and door-
side across frames, and for horizontal alignment of I/E stations across
frames.
Note: This graphical report is not generated for libraries with only
one frame.
• If the graphical report shows a failed result for the drive-side or
door-side, make sure that all tape magazines are installed properly
on that side and that the calibration targets are correctly snapped
on to the magazines.
• If the graphical report shows a failed result for the I/E station, make
sure the I/E station and front door are completely shut.
• If running the test again still generates failed results, realign the
middle X-axis rail and check the alignment of the top and bottom X-
axis rails at the location of the failure.
See
Figure 53
on page 610.
Chapter 15: Maintaining Your Library
Maintenance Actions
609
