Diagram 7; Town Villas System With Villa Shunt 323016 - LEGRAND D45 SYSTEM Installation Manual

WIRING DIAGRAMS

Diagram 7

town villas system witH villa sHunt 323016

88
323016
1 2
on
off
B/W
sIGNAL
1 2
ITEM
322011
322020
323005
323010
323003
323002
321070
323016
L1
PB
From main P. S.
DIsTANcE 1 2
200 m OFF OFF
ON OFF
200 - 400 m
OFF ON
400 - 500 m ON ON
DEscrIPTION
Digital call entrance panel
mall entrance panel
Main power supply
Auxiliary power supply
Riser shunt
Floor shunt
Floor shunt
Villa shunt
Electric door lock 12V - 4A impulsive
Door lock release pushbutton
323003
4 4
3 3
2 2
1 1
323005
A B C D
+ – – +
mx 200 m
WARNINGS:
„ „
Configure and insert the jumpers with the system
SWITCHED OFF. Also every time the configuration is
modified the pws must be switched OFF and ON again,
waiting about 1 minute.
A
To install alternative internal units, refer to
wiring variant section refer to WIRING DIAGRAM
VARIANTS.
B
To install alternative Entrance panel, refer to
wiring variant section.
Device configuration by SF2 software.
C
Set internal IMPEDANCE SWITCH to ON.
D
To install door lock accessory 323015, refer to
"ACCESSORY VERSIONS" section.
322011
To next riser
shunt 323003
BUS
L + L – UNLOCK
C
L1
B
+12
PB
