GENERAL FEATURES
System composition
APARTMENT BLOCK WITH 1 MAIN ENTRANCE PANEL AND MORE SECONDARY ENTRANCE PANELS
COMMON SYSTEM SECTION
Main entrance panel
16
To next
riser shunt
Power supply 323005
Power supply 323005
Power supply 323005
Riser shunt 323003
Riser shunt 323003
Power supply 323005
Riser shunt 323003
