LEGRAND D45 SYSTEM Installation Manual page 17

audio and Video HandSeTS
audio and video handsets for the audio and video reception of entrance panel calls. using the available icons, the advanced
devices can be used to manage the video door entry system functions and the home automation functions. available in
various look and installation models.
7" / 10" TOUCh SCREEN
INTERNAL UNIT
321070 / 321071
Colour video
Handsfree
Finishes / White finish
colours metal cover
Touch screen 7" / 10.2"
Display
800 x 480
Memory
function
SD CARD slot
Alarm
management
SOS function
Door lock
release
Scrolling EP
activation
Intercom
Power supply 30 Vdc
Type of
Wall mounted
installation
www.lEgranD.com
COLOUR hANDS COLOUR hANDS
FREE 7" ALARM FREE 3.5" ALARM
322050 321011
White White
7" 3.5"
480 x 234 320 x 240
— —
— —
30 Vdc 30 Vdc
Wall mounted Wall mounted
COLOUR hANDS COLOUR hANDS
gREE 7" FREE 3.5"
322052 321060
White White
7" 3.5"
480 x 234 320 x 240
— —
— —
— —
—
30 Vdc 30 Vdc
Wall mounted Wall mounted
D45 SyStEm
COLOUR hANDS
FREE 4.3"
321061
White
4.3"
—
—
—
30 Vdc
Wall mounted
GUIDE 9
