Accessory configuration examples

323003
riser shunT configuraTion
Possible riser shunt configuration
procedure.
Mode 1
Resistor configuration √
Keyboard configuration √
Use RS232 configuration ×
Riser shunt configuration position
C: the Switchboard number that is
the first priority for this riser.
If the number of the Switchboard
is more than 9 (from 10 to 15), this
parameter can only be set using the
riser shunt keyboard or the SF2.
M: System configuration Mode.
If the selected configuration Mode
is Mode 1 or Mode 2, this parameter
is 0. If this configurator is set using
WWW.LEGRAND.COM
meaning of each
configuraTor socKeT pin
NNNN: number of riser shunts.
#FF: typical floor number for riser.
#II: typical number of handsets
poSition Mode 1
Mode 2
CF1
√
CF2
NNNN
√
CF3
CF4
×
CF5
#FF is 20(default).
No need for configuration
CF6
CF7
#II is 4(default).
No need for configuration
CF8
C C
M M
4 4
3 3
2 2
1 1
number 2, it means that this riser
shunt is only used inside the riser
to extend the maximum number of
handsets (from 400 to 800).
If 323011 is present in the system or
switchboard is install in the riser than
configuration Bit
CF11 CF12
CF13 CF14
CF15 CF16
for each floor.
#Min handset: the lowest handset.
address managed by this riser shunt.
#Max handset: the highest handset
address managed by this riser shunt.
Mode 2
NNNN
#FF
(#II setup using same value for all system riser shunts)
#II
(#II setup using same value for all system riser shunts)
C
M
CF1 CF2 CF3 CF4 CF5 CF6 CF7 CF8 C
N N N N #F #F #I #I
an additional configuration is needed
for riser shunt as below listed:
configuration can only be set by SF2
software or by keyboard.
definition
First EP number in this riser
Riser EP quantity of riser
Riser switchboard number
M
C M
reMark
From 1 to 80
From 1 to 15
D45 SyStEm GUIDE 47
