Lift control interface
Configuration
(M = 2 to 9) meaning of the configurators :
CONFIGURATION PLACE
CF1 (N=1)
The corresponding OUTPUT channel
CF2 (N=2)
The corresponding OUTPUT channel
CF3 (N=3)
The corresponding OUTPUT channel
CF4 (N=4)
The corresponding OUTPUT channel
CF5 (N=5)
The corresponding OUTPUT channel
CF6 (N=6)
The corresponding OUTPUT channel
CF7 (N=7)
The corresponding OUTPUT channel
M
WARNING
- The relationship between CF(N) and CF(N+1) should meet the rule : CF(N+1) = CF(N) or CF(N+1) = CF(N) + 1
- The configuration value indicate the output channel of the entrance panel address
- Using configuration MODE (M=2 to 9),each channel correspond to one entrance panel address. The entrance panel address can be calculated by the following rule : A=(M-2) x 7 + N.
A means Entrance Panel address, M means MODE, N means configuration place such as CF1 means N=1. The phisical configuration value means the channel number.
CF1
M=2
1
M=3
8
M=4
15
M=5
22
M=6
29
M=7
36
M=8
43
M=9
50
(M = 2 to 9) Configuration example 3 :
System with : 2 entrance panels in the underground floor, 3 entrance panels in the 1.st floor. Floors 2 to 9 are "PRIVATE" floors and each floor has 4 apartments.
By setting delay time to 20 seconds (CF7 = 2), the configuration values of the two interfaces will be as follows :
CONFIGURATION PLACE
CF1
CF2
CF3
CF4
CF5
CF6
CF7
M
WARNING
By this configuration method, DEVICE 1 (OUTPUT 1) will manage the 2 entrance panels (EP with address 1 and 2) of the underground floor; DEVICE 1 (OUTPUT 2) will manage the 3
entrance panels (EP with address 3 to 5) of the 1.st floor; DEVICE 2 (OUTPUTS 1 to 8) will manage the "PRIVATE" floors 2 to 9.
CONFIGURATION VALUE
M=2–9
CF2
CF3
2
3
9
10
16
17
23
24
30
31
37
38
44
45
51
52
CONFIGURATION VALUE
DEVICE 1
DEVICE 2
1
0
1
2
2
0
2
4
2
8
0
0
0
2
2
1
BT00792-a-
CF4
CF5
4
5
11
12
18
19
25
26
32
33
39
40
46
47
53
54
en
25/11/2013
323017
CF6
CF7
6
7
13
14
20
21
27
28
34
35
41
42
48
49
55
56
231
