LEGRAND D45 SYSTEM Installation Manual page 132

Colour 5.6" handsfree indoor handset
Connection way for NC and NO contacts
PIN AlArM ArEA
F1 SENSOR 1
F2 SENSOR 2
F3
SENSOR 3
F4 SENSOR 4
F5
SENSOR 5
F6 SENSOR 6
F7 SENSOR 7
F8 SENSOR 8
gND
+ 12 v
128
SENSOr TYPE
THEFT ALARM
FIRE ALARM
Infrared or non-infrared;
Default is infrared sensor;
User can set it to be non infrared
Infrared or non-infrared;
Default is non-infrared sensor;
User can set it to be non infrared
THEFT ALARM
Infrared or non-infrared;
Default is infrared sensor;
User can set it to be non infrared
Infrared or non-infrared;
Default is non-infrared sensor;
User can set it to be non infrared
BT00468-b-en
SENSOr TYPE
Can use short key to sensor active or idle
INFRARED SENSOR
DOOR SENSOR
Can't use short key to let sensor idle
SMOKE SENSOR
GAS SENSOR
Can use short key to sensor active or idle
15/05/2013
321010
REMARK
