LEGRAND D45 SYSTEM Installation Manual page 193

Colour 7" handsfree indoor handset
Two different device configuration ways available:
WAY 1) Configuration settings by device keyboard
WAY 2) Configuration settings by inserting phisical configurators
Configuration settings by device keyboard - WAY 1 :
SETUP OPErATION CODE AND
lIghT STATUS
Set room number for 11#
handset 8 alarm lights and message light off
Set maximum 12#
apartments quantity 8 alarm lights and message light off
per floor in a riser
Set external SOS to be 15#
always on or always off message light will indicate status of
this setting item
Enable and disable 17#
function of monitoring message light will indicate status of
Small EP this setting item
Return all the 19#
parameters to default message light will indicate status of
value this setting item
Enable and disable 21#
sensors Message light is off. 8 alarm lights
will indicate status of each alarm
zone
22#
Set NO and NC type of
sensors 8 alarm lights will indicate status of
each alarm zone.
INSTAllATION SETTINgS OPErATION lIST TABlE
NExT MEANINg AND INFOrMATION FOr ThE OPErATION
OPErATION
"FFII#" correct parameter input: 1 long tone
wrong parameter input: 3 short tones
* return to main menu of installation setup, 1 short tone
other unsuccessful operation: 3 short tone
"II#" or "I#" correct parameter input: 1 long tone
wrong parameter input: 3 short tones
* return to main menu of installation setup, 1 short tone
other unsuccessful operation: 3 short tones
1 SOS external switch or pushbutton always
open (NO): message light on, 1 long tone
0 SOS external switch or pushbutton always close (NC): message light off, 1 long tone
* return to main menu of installation setup, 1 short tone
other unsuccessful operation: 3 short tones
1 enable: handset can monitor Small EP: message light on, 1 long tone
0 Shielded: handset can not monitor Small EP: message light off, 1 long tone
* return to main menu of installation setting, 1 short tone
other unsuccessful operation: 3 short tones
1 Get all the default parameters: message light on, 1 long tone
0 Do not get all the default parameters: message light off, 1 long tone
* return to main menu of installation setup, 1 short tone
other unsuccessful operation: 3 short tones
1# 1 1 alarm zone with sensor: LED 1 on, a long tone.
0 1 alarm zone without sensor: LED 1 off, a long tone.
* return to previous menu, 1 short tone
other Ineffective operation: 3 short tones
... ...
8# 1 8 alarm zone with sensor: LED 8 on, a long tone.
0 8 alarm zone without sensor: LED 8 off, a long tone.
* return to previous menu, 1 short tone
other unsuccessful operation: 3 short tones
* return to main menu of installation setting, 1 short tone
other unsuccessful operation: 3 short tones
1# 1 always open (NO) sensor for alarm area 1: LED 1 on, 1 long tone
0 always close (NC) sensor for alarm area 1: LED 1 off, 1 long tone
* return to previous menu, 1 short tone
other unsuccessful operation: 3 short tones
... ...
8# 1 always open (NO) sensor for alarm area 8: LED 8 on, 1 long tone
0 always close (NC) sensor for alarm area 8: LED 8 off, 1 long tone
* return to previous menu, 1 short tone
other unsuccessful operation: 3 short tones
* return to main menu of installation setup, 1 short tone
other unsuccessful operation: 3 short tones
BT00472-b-en 03/06/2013
322050
rEMArk
Default room number: 101
Range:1-99
Default:4; it can be set only when
there is no setting for hardware
Default: always
open
Default: cannot monitor Small EP. This
function is available only when the
function is set as Small EP function.
Default: (all) without sensor
Default: sensors for 8 alarm zones are
always open (NO).
189
