LEGRAND D45 SYSTEM Installation Manual page 85

321070
A
321070
A
WARNINGS:
„ „
Configure and insert the jumpers with the system
SWITCHED OFF. Also every time the configuration is
modified the pws must be switched OFF and ON again,
waiting about 1 minute.
A
To install alternative internal units, refer to
wiring variant section.
B
To install alternative Entrance panel, refer to wiring
variant section.
Device configuration by SF2 software.
C
Set internal IMPEDANCE SWITCH to ON.
D Auxialiary PWS must be used in relation with the system
distance extension - see specific section.
WWW.LEGRAND.COM
x x 0 2
F F I I #I #I
BUS
x x 0 1
1 2
F F I I #I #I
BUS
ITEM DEscrIPTION
322011 Digital call entrance panel
323005 Main power supply
323010 Auxiliary power suppsly
323002 Floor shunt
321070 7" Touch screen internal unit
L1 Electric door lock 12V - 4A impulsive
PB Door lock release pushbutton
To next floor
shunt 323002
321070
A
323002
321070
A
323010
A B C D
+ – – +
x x 0 3
F F I I #I #I
BUS
x x 0 4
F F I I #I #I
BUS
D
D45 SyStEm GUIDE 77
