Power supply
Configuration
Choosing system power solution:
- Solution 1: PWS 323005 will be chosen as system power supply inside riser while
auxiliary PWS (323010) will be chosen for all the assistant power supply.
- Solution 2: PWS 323005 will be chosen for both system power supply inside riser and
assistant power supply.
Note: when the system has Small EP, solution 2 will be helpful to avoid possible damage
to the power supply in the system. When the system has IU connected with Small EP, at
some occasions, if several Small EPs call IU at the same time, it will make power supply
overloaded.
Under this situation, the power supply is at risk to be damaged.
Suggested power supply solution and related configuration:
NO. SYSTEM PWS
SOLUTION
ALARM SMALL
EP
1 No No 1
2
No No 1
3 Yes No 1
4
Yes No 1
5
No Yes 2
6 No Yes 2
7 Yes Yes 2
8 Yes Yes 2
Note: X = means no need any configurator, it also means the configurating position is 0; others need configurator with requested value. √ = means need configuration here.
CONFIGURATION WHEN PWS IS SYSTEM POWER SUPPLY
(IMPEDANCE SWITCH OF PWS MUST BE ON)
CF1 CF4 CF12 CF13
~ ~
CF3 CF11
(NNN) (TYPE) (ASR)
X X X X
X X X X
X X X X
NNN X 1 0.2–9
NNN √ 1 1
NNN √ 1 1
NNN √ 1 0.2~9
NNN √ 1 0.2~9
BT00453-b-en
CONFIGURATION OF PWS AND AUXILIARY PWS WHEN PWS IS
AUXILIARY POWER SUPPLY (IMPEDANCE SWITCH OF POWER
CF14 CF15 CF1 CF4
~ ~
CF3 CF11
(M) (LE) (NNN)
X X
X X
Here use Auxiliary Power supply, configuration is not necessary.
X X
1 X
0/1 X X √
0/1 X X √
0/1 X X √
0/1 X X √
13/05/2013
323005
SUPPLY MUST BE OFF)
CF12 CF13 CF14 CF15
(TYPE) (ASR) (M) (LE)
2 1 0/1 X
2 1 0/1 X
2 0.2–9 0/1 X
2 0.2–9 0/1 X
