WIRING DIAGRAMS - VARIANTS
Diagram 10

connection of entrance Hall pusHbutton to tHe entrance panel

L+ L-

Diagram 11

floor call connection

Diagram 12

back-up battery connection

104
322010
GND DAS UNLOCK +12V GND
INTERNAL UNIT
323005 / 323010
A B C D
+ – – +
323005 / 323010
A B C D
+ – – +
A B C D
+ – – +
BACK BONE
L+ L- DAS
Enable the service with the code:
#686868#16#1 "LONG TONE".
24Vdc BATTERY
12Vdc BATTERY 12Vdc BATTERY
322011
UNLOCK +12V GND
24Vdc BATTERY
