WIRING DIAGRAMS - VARIANTS

Diagram 1

iu wired connection + alarm connection

SENSOR
GND 12V F1
Handset
323002
1 2
POWER – +
96
ALARM SENSORS
SENSOR
GND 12V
To IU 2
To IU 3
To IU 4
Sub System OUT
F8
F1
F2
F3
F4
F5
F6
F7
F8
GND
12V
R1
R2
R3
R4
To SOS button
+
–
323015
Adaptor 15 V/2 A
1 2 3 4
A B C D
+ – – +
POWER
- +
+
–
Normally a standard 0.5 mm cable can be used
2
(depending on sensor type and installation distance)
For video signals a standard cable can be used.
For data signals use a 0.5 mm cable
2
(in accordance with installation distances)
Small EP
Electronic lock
