LEGRAND D45 SYSTEM Installation Manual page 135

3.5 " Colour handsfree internal unit
Configuration
Two different device configuration ways available:
Configuration settings by device keyboard - WAY 1
Configuration settings by inserting phisical configurators - WAY 2
Configuration settings by device keyboard - WAY 1:
When the handset is in standby and all zone alarms are disabled, press "#", then enter
the fixed installer password 686868, and press "#" to confirm. If the wrong password
is entered, 3 short beeps will be heard; if the password is correct, an extended beep will
be heard, and the unit will switch to installation setup status. The 8 alarm lights and the
message light will be off.
SETUP OPErATION CODE AND
lIghT STATUS
Set room number for 11#
handset 8 alarm lights and message
light off
Maximum 12#
apartments quantity 8 alarm lights and message
per floor in a riser light off
Set external SOS 15#
to be always on or message light will indicate status
always off of this setting item
Enable and 17#
disable function of message light will indicate status
monitoring Small EP of this setting item
Return all the 19#
parameters to message light will indicate status
default value of this setting item
Enable and disable 21#
sensors Message light is off. 8 alarm
lights will indicate status of each
alarm zone
22#
Set NO and NC type
of sensors 8 alarm lights will indicate status
of each alarm zone.
INSTAllATION SETTINgS OPErATION lIST TABlE
NExT MEANINg AND INFOrMATION FOr ThE OPErATION
OPErATION
"FFII#" correct parameter input: 1 long tone
wrong parameter input: 3 short tones
* return to main menu of installation setup, 1 short tone
other unsuccessful operation: 3 short tone
"II#" or "I#" correct parameter input: 1 long tone
wrong parameter input: 3 short tones
* return to main menu of installation setup, 1 short tone
other unsuccessful operation: 3 short tones
1 SOS external switch or pushbutton always
open (NO): message light on, 1 long tone
0 SOS external switch or pushbutton always close (NC): message light off, 1 long tone
* return to main menu of installation setup, 1 short tone
other unsuccessful operation: 3 short tones
1 enable: handset can monitor Small EP: message light on, 1 long tone
0 Shielded: handset can not monitor Small EP: message light off, 1 long tone
* return to main menu of installation setting, 1 short tone
other unsuccessful operation: 3 short tones
1 Get all the default parameters: message light on, 1 long tone
0 Do not get all the default parameters: message light off, 1 long tone
* return to main menu of installation setup, 1 short tone
other unsuccessful operation: 3 short tones
1# 1 1 alarm zone with sensor: LED 1 on, a long tone.
0 1 alarm zone without sensor: LED 1 off, a long tone.
* return to previous menu, 1 short tone
other Ineffective operation: 3 short tones
... ...
8# 1 8 alarm zone with sensor: LED 8 on, a long tone.
0 8 alarm zone without sensor: LED 8 off, a long tone.
* return to previous menu, 1 short tone
other unsuccessful operation: 3 short tones
* return to main menu of installation setting, 1 short tone
other unsuccessful operation: 3 short tones
1# 1 always open (NO) sensor for alarm area 1: LED 1 on, 1 long tone
0 always close (NC) sensor for alarm area 1: LED 1 off, 1 long tone
* return to previous menu, 1 short tone
other unsuccessful operation: 3 short tones
... ...
8# 1 always open (NO) sensor for alarm area 8: LED 8 on, 1 long tone
0 always close (NC) sensor for alarm area 8: LED 8 off, 1 long tone
* return to previous menu, 1 short tone
other unsuccessful operation: 3 short tones
* return to main menu of installation setup, 1 short tone
other unsuccessful operation: 3 short tones
BT00763-a-en 13/05/2013
321011
rEMArk
Default room number: 101
Range:1-99
Default:4; it can be set only when
there is no setting for hardware
Default: always
open
Default: cannot monitor Small
EP. This function is available only
when the function is set as Small
EP function.
Default: (all) without sensor
Default: sensors for 8 alarm zones
are always open (NO).
