Lift control interface
Configuration
Lift control interface can be configured in 9 different modes
(M = 1 to 9), depending on the following main requested
features :
(M = 1) - suggested in case of floor with 1 entrance panel and total system entrance
panel number less than 9.
(M = 2 to 9) - suggested in case of floor with more than 1 entrance panel or total system
entrance panels higher than 8.
Two different device configuration ways available:
WAY 1) Configuration settings by inserting phisical configurators
WAY 2) Configuration by using SF2 Software and PC connection
CONFIGURATION SETTINGS BY INSERTING PHISICAL CONFIGURATORS - WAY 1 :
MODE (M = 1) meaning of the configurators :
CONFIgUrATOr MODE 1
CF1
CF2
CF3
CF4
CF5 (*1)
CF6 (*1)
CF7 (*2)
M
WARNINGS :
(*1) - CF5 + CF6 must be ≤ 8
(*2) - Entrance panel calls internal unit and internal unit unlock,the output relay connected to the floor entrance panel act,after delay time,the output relay connected to the floor
internal unit act.
CF7 Delay time selection table
CF7 Configurator 0
Delay time (sec.) 1"
CF1 CF2 CF3 CF4 CF5 CF6 CF7 M
DESCrIPTION
FF FF is corresponding to the 1st. PRIVATE floor (IU floor) managed by the device
#II Apartment number for each floor
Quantity of PRIVATE floor (IU floor) managed by the device
Quantity of PUBLIC floor (EP floor) managed by the device
Delay time setting (see specific table below)
Mode selection (1)
1 2
10" 20"
BT00792-a-
Indication lights instruction for the
corresponding lift control.
EP call IU and IU unlock
EP unlock with card or password
IU unlock in idle
Stand by
3 4 5
30" 40" 50"
en 25/11/2013
323017
(l1) lED
Flash
Flash No action
No action
No action No action
6 7 8
60" 70" 80"
(l2) lED
Flash
Flash
9
90"
