GENERAL FEATURES
System composition
SINGLE BUILDING WITH MORE RISERS
For the installation of video systems
with several branches, the 2-way video
BRANCH 1 FLOOR 1
Apartment 2
Apartment 1
Entrance panel
14
splitter, 323007, and the floor shunts,
323002, can be used.
Floor shunt 323002
2-Way Video
Splitter 323007
To floor
shunt 323003
Power supply 323005
Apartment 3
Apartment 4
