322010
322011
Digital calls colour entrance panels
Pack Cat.Nos
Zamak digital call street panel with keyboard,
LCD display and colour camera
Equipped with door lock release and burglar
alarm notification
Configuration screen menu and software
upgrade without the need to dismantle the
device
Flush-mounting installation (flush-mounting box
sold with the street panel)
1 BT-322010 Without addresses list
BT-322011 With addresses list
1
Nameplate module
BT-322012 Zamak nameplate module to install at the side
1
of the digital call street panel Cat.No BT-322011
to insert the list of residents or customised
messages
Easy insertion / replacement of nameplates
Flush-mounting installation (flush-mounting box
supplied)
Pushbutton call colour street panels
Zamak pushbutton street panel with
pushbuttons colour camera. Flush-mounting
installation
(flush-mounting box supplied)
1 BT-322030 With 10 call pushbuttons
1 BT-322031 With 20 call pushbuttons
Dimensional data
MODEL NAME
Entrance panel with call address list
Small entry panel color
Floor call entry panel
10 Call pushbuttons entrance panel
20 Call pushbuttons entrance panel
16 Additional pushbuttons panel
32 Additional pushbuttons panel
Targa module
110
322030 322031
CODE NUMBER
322011
322020
322021
322030
322031
322032
322033
322012
322032 322033
Additional pushbutton module
Pack Cat.Nos
Additional Zamak pushbutton panel with
pushbuttons on single column
Easy insertion / replacement of nameplates
Flush-mounting installation (flush-mounting box
supplied)
1 BT-322032 With 16 call pushbuttons
BT-322033 With 32 call pushbuttons
1
Single call small entrance panel
BT-322020 Aluminium alloy single call small street panel to
1
be installed in one-family systems or as private
street panel in multifamily systems
Touch-sensitive pushbutton for calling indoor
handsets and direct conversation
Double verified intercom calls
Surface-mounting
Floor call entry panel

BT-322021

1 Plastic single call small panel to be installed in
one-family system
Surface mounting
1 module
1 BT-322001 Box for street panel wall-mounting installation
Rainshield integrated
Compatible with Cat.No:
- BT-322010 (digital street panel)
- BT-321011 (digital street panel with address
list)
- BT-321030 (10 pushbutton street panel)
- BT-321031 (20 pushbutton street panel)
2 modules
BT-322002
1 Box for street panel wall-mounting installation
Rainshield integrated
Compatible with Cat.No:
- BT-322010 (digital street panel)
- BT-321011 (digital street panel with address
list)
- BT-321030 (10 push button street panel)
- BT-321031 (20 push button street panel)
- and one expansion module:
BT-321012 (targa module) or BT-321032 (16
pushbutton extension) or BT-321033 (32
pushbutton extension)
DIMENSIONS (mm)
325 x 125 x 44,5
141 x 108 x 31
152 x 104 x 25
325 x 125 x 63
325 x 125 x 63
325 x 125 x 44,5
325 x 125 x 44,5
325 x 125 x 44,5
322020 322021
