LEGRAND D45 SYSTEM Installation Manual page 163

Digital colour entrance panel
with addresses list
Configuration & Settings
Entrance panel must be configured for the following parameters:
NN
N N R R R R
RRRR : NOT USED
Two different device configuration ways available:
WAY 1) Configuration settings by device keyboard
WAY 2) Configuration by using SF2 Software and PC connection
Configuration settings by device keyboard - WAY 1:
Welcome
Access to the configuration menù by press and hold the door lock key
for more than 10 seconds.
PASSWORD
Enter the access code (DEFAULT 1 2 3 4)
PASSWORD
1 2 3 4
If the correct code has been entered, direct access to the configuration menù will be granted.
cONFIguRAtION
Language
Panel settings
Address book
To exit from the configuration menù, or to return to the previous menù, select EXIT than press OK.
: Entrance panel number
Phonic module settings
FW versions
EXIt
BT00853-a-en
cONFIguRAtION
03/09/2014
322011
159
