LEGRAND D45 SYSTEM Installation Manual page 40

GENERAL RULES FOR INSTALLATION
System cable
caBles used
032750
032754
32
cat. 5e u/utp caBleS
Category 5E U/UTP unshielded cable with 24AWG (0.51 mm) solid copper conductors, polyolefin insulation,
4 pairs of twisted conductors with internal separator - in accordance with ISO/IEC 11801,
and 2.0, EN 50173-1 and EIA/TIA 568 B2.10 standards - grey colour.
U/UTP Sheath
032750 LSZH
032751 PVC
032873 LSZH
032874 PVC
cat. 6 u/utp caBleS
Category 6 U/UTP unshielded cable with 24AWG (0.51 mm) solid copper conductors, polyolefin insulation,
4 pairs of twisted conductors with internal separator - in accordance with ISO/IEC 11801,
and 2.0, EN 50173-1 and EIA/TIA 568 B2.10 standards - blue colour.
U/UTP Sheath
032754 LSZH
032871 LSZH
032872 PVC
Length Packaging
305 m box
305 m box
1000 m reel
1000 m reel
Length Packagings
305 m reel
1000 m reel
1000 m reel
