WIRING DIAGRAMS - VARIANTS
Diagram 2
basic apartment interface connection
A
The indoor units must have the same address FFII#I#I.
98
323008
POWER – +
323002
1 2
POWER – +
Sub System OUT
Remarks:
when the total power consumption for all
handsets connected to 323008 exceeds the
limit, an auxiliary power supply (323010)
is required.
To IU 4
handset
A
handset
A
handset
A
