LEGRAND D45 SYSTEM Installation Manual page 194

Colour 7" handsfree indoor handset
Configuration
SETUP OPErATION CODE AND
lIghT STATUS
Set infrared sensor 23#
Message light is off. 8 alarm
lights will indicate status
of infrared sensor. Setting:
infrared sensor: light of
this alarm zone will be on.
Non-infrared sensor, light of
this alarm defence area zone
will be off.
Setting for Time 24#
delay after alarm The light of the zone indicates
set the parameter For example, if
the parameter is 3, then LED
3 will on
Setting for Time 25#
delay after alarm The light of defence area give
happens the parameter. For example, if
the parameter is 3, then LED
3 will on
Enable and disable 26#
sound alarm for The Information LED indicates
thief the setup state
*
other
1) 16#
Doorbell function The information LED to give
setup(if is doorbell setup state
function , it is not
Small EP function)
2) 13#
Handset connec- The information LED to give
tion to Apartment setup state
interface function
setup
190
INSTAllATION SETTINgS OPErATION lIST TABlE
NExT MEANINg AND INFOrMATION FOr ThE OPErATION
OPErATION
5# 1 infrared sensor for alarm zone 5: LED 5 on, 1 long tone
0 non- infrared sensor for alarm zone 5: LED 5 on, 1 long tone
* return to previous menu, 1 short tone
other unsuccessful operation: 3 short tones
...... ... ...
8# 1 infrared sensor for alarm zone 8: LED 8 on, 1 long tone
0 Non- infrared sensor for alarm zone 8: LED 8 on, 1 long tone
* return to previous menu, 1 short tone
other unsuccessful operation: 3 short tones
* return to main menu of installation setup, 1 short tone
other unsuccessful operation: 3 short tones
1 delay 40 s: 1 long tone, only LED 1 will on
2 delay 100 s: 1 long tone, only LED 2 will on
3 delay 150 s: 1 long tone, only LED 3 will on
4 delay 210 s: 1 long tone, only LED 4 will on
5 delay 255 s: 1 long tone, only LED 5 will on
* return to main menu of installation setup, 1 short tone
Other unsuccessful operation: 3 short tones
1 delay 40 s: 1 long tone, only LED 1 will on
2 delay 100 s: 1 long tone, only LED 2 will on
3 delay 150 s: 1 long tone, only LED 3 will on
4 delay 210 s: 1 long tone, only LED 4 will on
5 delay 255 s: 1 long tone, only LED 5 will on
* return to main menu of installation setup, 1 short tone
other unsuccessful operation: 3 short tones
enabled: if there is a burglar alarm, loudspeaker will emit a sound. Mes-
1
sage light on, 1 long tone
disabled: if there is a burglar alarm, loudspeaker will not emit a sound.
0
Message light off, 1 long tone.
* return to main menu of installation setup, 1 short tone
other unsuccessful operation: 3 short tones
exit main menu of installation setup, 1 short tone
unsuccessful operation: 3 short tones
1 Enable doorbell function, the information LED is on, 1 long tone.
0 Disable doorbell function, the information LED is off, 1 long tone
* return to main menu of installation setup, 1 short tone
other unsuccessful operation: 3 short tones
1 handset has connected to the Apartment interface the information LED is
on, 1 long tone,
0 handset has not connected to the Apartment interface, the information LED is
off, 1 long tone.
* return to main menu of installation setup, 1 short tone
other unsuccessful operation: 3 short tones
BT00472-b-en 03/06/2013
322050
rEMArk
Note: 1/2/3/4 alarm zone are
defined as infrared alarm zones,
door alarm, smoke alarm, gas
alarm. They cannot be changed.
5/7 are defaulted as infrared
alarm zones s. 6/8 alarm are
defaulted as non-infrared alarm
zones
Default: 100 s
only for thief area alarm
Default: 40 s
only for thief area alarm
Default: no sound
Default: is not doorbell fun-
ction, tt is Small EP function.
Default: Handset not
connected to the Apartment
interface.
