EP configuration examples

322010
digiTal enTrance panel
configuraTion
Possible EP configuration modes
Mode 1
Resistor configuration √
Keyboard configuration √
RS232 configuration √
meaning of each
configuraTor socKeT pin
NN: the number for the main EP, the
number range is from 1 to 80, which
means that the maximum main EP in
riser is 80 (default value: 1).
#FF: typical floors per riser.
#II: typical number of handsets per floor.
Example (A):
EP address is 5, each riser has 20
floors, and each floor has 4 handset:
system configuration Mode 1 is used.
The Switchboard directly connected
to the main EP is no. 2, main EP
configuration should be as follows:
A
WWW.LEGRAND.COM
Mode 2
N N #F #F #I #I
√
√
√
poSition Mode 1
N
NN
N
#FF is 20 (default).
No need for configuration
#II is 4 (default).
No need for configuration
poSition
N
N
#F
#F
#I
#I
C 2 This position can use the EP keyboard or the configuration tool for the configuration.
Note: the other configuration position C is for
setting the Switchboard address number that will
communicate with the EP directly. The configuration
position C can only be configured using the EP
keyboard or the configuration tool software.
(C default value: 0; this means that the Switchboard
that will communicate with the EP is No.0).
Mode 2
Mode 2= Mode 1
#FF
(use EP keyboard config or 323020 download config)
(use EP keyboard config or 323020 download config)
Value for configurator reMarkS
0 0
5
#FF is 20(default).
No need for configuration
#II is 4(default).
No need for configuration
N N #F #F #I #I
0 5
D45 SyStEm GUIDE 43
