Handset configuration examples

321011
possiBle handseT
configuraTion procedure
Mode 1
Resistor configuration
(only for Colour)
Keyboard configuration √
RS232 configuration
×
meaning of each
configuraTor socKeT pin
FF: Handset floor number.
II: handset household number.
#II: typical number of handsets
per floor.
Example (A):
The number of handsets is 1204,
each floor has 4 handsets, the
system configuration Mode is
Mode 1, the handset configuration
should be as follows:
A
WWW.LEGRAND.COM
Configurators position for handsets
Mode 2
×
Mode 1
poSition
F
FF
F
I
II
I
#I
Default for #II is 04,
need not connect the configurator
#I
poSition
configuration Value
F
1
F
2
I
0
I
4
#I
#I
F
F
I
Mode 2
FF
II
II
(#II setup using same value for all system handsets)
reMarkS
It is ok not to insert configurator 0
Because the default value of #II is 4, no configurator
is needed
F
F
I
I
#I #I
1 2 0 4
D45 SyStEm
I
#I #I
GUIDE
45
