8 floors building. Floors 4 to 8 are "PRIVATE" floors and each floor has 4 apartments. Floors 1 to 3 are "PUBLIC" floor and each floor has 1 entrance panel. The entrance panel adresses are

1 to 3 in correspondance with the 1 to 3 floor number. By setting delay time to 20 seconds (CF7 = 2), the interface configuration value and the correspondance between device OUTPUT

and Entrance panel/Internal unit floor will be as follows

CONFIGURATION PLACE

CF1

CF2

CF3

CF4

CF5

CF6

CF7

WARNINGS :

- OUTPUT 1 to 5 will manage the corresponding "PRIVATE" floors 4 to 8.

- OUTPUT 6 to 8 will manage the "PUBLIC" floors 1 to 3.

(M = 1) Configuration example 2 :

14 floors building. Floors 2 to 14 are "PRIVATE" floors and each floor has 4 apartments. The 1.st floor is the "PUBLIC" floor and has 1 entrance panel. N°2 lift control interface are requested

to manage this system. By setting delay time to 10 seconds (CF7 = 1), the configuration values of the two interfaces will be as follows :

CONFIGURATION PLACE

CF1

CF2

CF3

CF4

CF5

CF6

CF7

WARNING

- By this configuration method, DEVICE 1 (OUTPUT 8) will manage the 1.st floor (PUBLIC floor).

OUTPUT 1 to 7 will manage floors 2 to 8 (PRIVATE floors). DEVICE 2 (OUTPUT 1 to 6) will manage floors 9 to 14 (PRIVATE floors).
