WIRING DIAGRAMS - VARIANTS

Diagram 6

wiring diagrams - door lock relay connection

L+ L-

Diagram 7

addictional poower supply connection
323005 / 323010
+ – – +
102
322010
322011
N.B.: Cable size 1 mm and max distance 2 meters
2
A B C D
N
Riser IN
346250
NC NO
S- S+ C
N L
E
Blue N
-
- Yellow and green
Brown
- L
AC input
This wire must be connected
to earth ground
L
8A cosϕ = 1 24 Vac/24 Vdc
NO
4A cosϕ = 0.7 24 Vac
NC
3A cosϕ = 0.4 24 Vac
C
323002
1 2
Riser OUT
