LEGRAND D45 SYSTEM Installation Manual page 142

3.5 " Colour handsfree internal unit
Configuration
Two different device configuration ways available:
Configuration settings by device keyboard - WAY 1
Configuration settings by inserting phisical configurators - WAY 2
Configuration settings by device keyboard - WAY 1:
When the handset is in standby mode, press and mantain the door lock key until a long tone is heard. With information & connection status LEDs OFF you are in settings mode. Then
within 10 seconds, press and mantain the call to the switchboard key until a long tone is heard to enter into the initial installation settings (you can set parameters without selecting
submenus).
FUNCTION
Access to the room code to set the submenu At initial setting status, short-press on the connection key once and enter into the room code of the indoor unit
Set the parameter
Set the displacement place and exit the
setting of the submenu
Exit
FUNCTION
Enter into the submenu to set the household
number of each floor
Set the parameter
Set the displacement place and exit the
setting of the submenu
Exit
138
SETTINg FOr ThE rOOM NUMBEr OF ThE INDOOr UNIT
OPErATION
to set the submenu. Note: on entering into the room code of the indoor unit to set the submenu, the initialized
place should be of the thousand-digit.
Press on the monitoring key and add 1 to the parameter of the relevant setting place. On adding to 10, three
short tones can be heard, meaning the wrong operation, and it automatically exit the submenu and return to the
initial installation status
Short-press on the door lock key to move to the next setting place, with the sequence of the thousands, the
hundreds, the tens and the ones places.
Note: 1) In the process to set the displacement place, if the parameter is not set, then take the default value at 0.
2) When the place moves to the ones, short-press on the door lock key again to exit the setting of the room
number and return to the setting status of the initial installation. At the exit, if the setting of the room
number of the indoor unit is correct, a long tone can be heard as a prompt. You can save it. If not correct,
three short tones will be heard, and no need to save it.
1) Short-press on the Door lock key and move to the last digit. Then short-press on the Door lock key again to
exit the room code of the indoor unit and setting of the submenu to return to the setting status of the initial
installation.
2) With a wrong operation, three short tones can be heard and it will automatically return to the setting status
of the initial installation.
SET MAxIMUM APArTMENTS qUANTITY PEr FlOOr IN A rISEr
OPErATION
At the setting status of the initial installation, short-press the Call to the switchboard key twice to enter into
the submenu and set the household number of each floor. Note: On setting the submenu, the initialized place
should be set at the tens place.
Short-press the MONITOr key and add 1 to the parameter of the relevant setting place. On adding to 10, three
short tones can be heard, meaning the wrong operation, and it automatically exit the submenu and return to the
setting status of the initial installation.
Short-press the Door lock key to move to the next place, which is the ones place.
Short-press the Door lock key and move to the next place, the sequence of which is the tens place to the
ones place. Exit the current setting options and return to the setting status of the initial installation. After
the displacement, the parameter of the displacement place can be set as 0. Before exit, check whether the
parameter is correctly set. If correct, one long tone can be heard and save it. If not, three short tones can be
heard, no need to save it.
1) Short-press the Door lock key twice and move to the last digit. Then short-press Door lock key again to exit
the current setting options of the submenu and return to the setting status of the initial installation.
2) With a wrong operation, three short tones can be heard and it will automatically return to the setting status
of the initial installation.
BT00764-a-en 30/05/2013
321060
rEMArk
The room number can be set in a
range from 101 to 9999. The ex-factory
default number is 101. The last two
digits after the 101 room code are not to
be bigger than the household number
of each floor.
rEMArk
The household number cannot be less
than the room numbers, ranging from
1 to 99, and the ex-factory default
value is 4.
