Diagram 4; Apartment Interface Connection - LEGRAND D45 SYSTEM Installation Manual

WIRING DIAGRAMS - VARIANTS

Diagram 4

apartment interface connection

Remarks: if powered through the unit bus system, only one indoor unit can be set as the master indoor unit.
To HANDSET 2
POWER – +
System input
(connect to 323002 - output)
100
To configure the interface
with address FFII#I#I
To HANDSET 3
POWER – +
1 2
To HANDSET 4
System output
(connect to 323002 - input)
323009
Handset
not configurated
323015 322020
