Digital colour entrance panel
with addresses list
Configuration & Settings
Speaker module settings - this configuration can be performed only with the module NOT phisically configured (NO configurators inserted).
ScS SEttINgS
P – Panel number 00
t – Lock time 1
Switchboard 00
P-Panel number: SCS address of the entrance panel
T-Lock time: door lock time delay (NOT USED)
Switchboard: SCS address of the switchboard (if present)
Signal type of lock:
NO = Normally open
NC = Normally closed
Dismantle alarm:
ON = alarm enabled
OFF = alarm disabled
Firmware version - this menu indicate you the firmware version installed on the device.
FW versions
Phonic mod. : 00.00.00
EXIt
Direct call to the switchboard - by pressing the dedicated pushbutton.
to call the switchboard
press the button
Door lock release by code- you can directly activate the door lock releasing by typing the associated numerical code. Press the key
Input unlock password
Switchboard
DOOR OPEN
