GENERAL RULES FOR INSTALLATION
Accessory configuration examples
Example (B):
This riser has 20 floors, and each floor
has 5 handsets. This power supply
manages 1-2 floors.
If necessary enable the smart power
function and the power management
function, the power supply address
is 12, max current of the alarm sensor
is 300 mA. System configuration
Mode 2 is used. The power supply
configuration should be as follows:
B
52
poSition Mode 1
CF1 N
CF2 N
CF3 N
CF4 FF Min
CF5 FF Min
CF6 #II
CF7 #II
CF8 FF Max
CF9 FF Max
CF10 CF10
CF11 CF11
CF12 Type
CF13 ASR
CF14 M
CF15 LE
