LEGRAND D45 SYSTEM Installation Manual page 139

3.5 " Colour handsfree internal unit
NC & NO alarm sensors connection table
PIN AlArM ArEA
F1 SENSOR 1
F2 SENSOR 2
F3
SENSOR 3
F4 SENSOR 4
F5 SENSOR 5
F6
SENSOR 6
F7 SENSOR 7
F8 SENSOR 8
gND
+ 12 v
SENSOr TYPE
THEFT ALARM
FIRE ALARM
Infrared or non-infrared;
Default is infrared sensor;
User can set it to be non infrared
Infrared or non-infrared;
Default is non-infrared sensor;
User can set it to be non infrared
THEFT ALARM
Infrared or non-infrared;
Default is infrared sensor;
User can set it to be non infrared
Infrared or non-infrared;
Default is non-infrared sensor;
User can set it to be non infrared
BT00763-a-en
SENSOr TYPE
Can use short key to sensor active or idle
INFRARED SENSOR
DOOR SENSOR
Can't use short key to let sensor idle
SMOKE SENSOR
GAS SENSOR
Can use short key to sensor active or idle
13/05/2013
321011
REMARK
135
