- Page 1 ™ DAQCard -1200 User Manual Multifunction I/O Card for the PCMCIA Bus DAQCard-1200 User Manual October 1999 Edition Part Number 320936B-01...
- Page 2 Switzerland 056 200 51 51, Taiwan 02 2377 1200, United Kingdom 01635 523545 For further support information, see the Technical Support Resources appendix. To comment on the documentation, send e-mail to techpubs@natinst.com. © Copyright 1995, 1999 National Instruments Corporation. All rights reserved.
-
Page 3: Important Information
Any action against National Instruments must be brought within one year after the cause of action accrues. National Instruments shall not be liable for any delay in performance due to causes beyond its reasonable control. -
Page 4: Table Of Contents
Contents About This Manual Organization of This Manual ...ix Conventions Used in This Manual...x National Instruments Documentation ...xi Related Documentation...xii Chapter 1 Introduction About the DAQCard-1200...1-1 What You Need to Get Started ...1-2 Software Programming Choices ...1-2 LabVIEW and LabWindows/CVI Application Software...1-3 NI-DAQ Driver Software ...1-3... - Page 5 Data Acquisition Timing... 4-8 Data Acquisition Operation ... 4-8 Continuous Data Acquisition... 4-8 Interval Data Acquisition... 4-9 Data Acquisition Rates... 4-9 DAQCard-1200 User Manual Floating Signal Sources... 3-6 Ground-Referenced Signal Sources ... 3-6 Differential Connection Considerations (DIFF Configuration) ... 3-7 Differential Connections for Grounded Signal Sources...
- Page 6 PC Card Questions and Answers Appendix E Technical Support Resources Glossary Index Figures Figure 1-1. The Relationship between the Programming Environment, NI-DAQ, and Your Hardware ...1-4 Figure 2-1. A Typical Configuration for the DAQCard-1200 ...2-2 © National Instruments Corporation DAQCard-1200 User Manual Contents...
- Page 7 Digital I/O Circuitry... 4-13 Tables Table 2-1. Analog I/O Settings... 2-3 Table 2-2. Analog Input Modes for the DAQCard-1200 ... 2-4 Table 3-1. Bipolar and Unipolar Analog Input Signal Range Versus Gain ... 3-5 Table 3-2. Recommended Input Configurations for Ground-Referenced and Floating Signal Sources...
-
Page 8: About This Manual
PC Card Questions and common questions and answers relating to PC Card operation. Appendix E, Technical Support to request help from National Instruments or to comment on our products and manuals. is organized as follows: Modes, describes the Answers, contains a list of... -
Page 9: Conventions Used In This Manual
PC refers to the IBM PC/XT, PC AT, Personal System/2, and laptop compatible computers which are equipped with a Type II, 5 V-capable slot and a PCMCIA standard version 2.0 or later bus interface. DAQCard-1200 User Manual Glossary contains an alphabetical list and description of terms used in this manual, including abbreviations, acronyms, metric prefixes, mnemonics, and symbols. -
Page 10: National Instruments Documentation
• • • • © National Instruments Corporation DAQCard-1200 User Manual Getting Started with SCXI—If you are using SCXI, this is the first manual you should read. It gives an overview of the SCXI system and contains the most commonly needed information for the modules, chassis, and software. -
Page 11: Related Documentation
• • • DAQCard-1200 User Manual Your NI-DAQ or LabVIEW software manuals for PC compatibles Your computer operating manual, which explains how to insert cards into the PC Card slot “Dither in Digital Audio” by John Vanderkooy and Stanley P. Lipshitz, Journal of the Audio Engineering Society, Vol. -
Page 12: Introduction
The DAQCard-1200 is fully software-configurable and calibrated so that you can easily install the card and begin your acquisition. The small size and weight of the DAQCard-1200 coupled with its low power consumption make this card ideal for use in portable computers, making portable data acquisition practical. -
Page 13: What You Need To Get Started
Detailed specifications of the DAQCard-1200 are in Appendix A, Specifications. What You Need to Get Started To set up and use your DAQCard-1200, you will need the following items: Software Programming Choices There are several options to choose from when programming your National Instruments plug-in DAQ and SCXI hardware. -
Page 14: Labview And Labwindows/Cvi Application Software
ANSI standard C programming language. The LabWindows/CVI Data Acquisition Library, a series of functions for using LabWindows/CVI with National Instruments boards, is included with your NI-DAQ software kit. The LabWindows/CVI Data Acquisition libraries are functionally equivalent to the NI-DAQ software. -
Page 15: Register-Level Programming
Chapter 1 Introduction Register-Level Programming The final option for programming any National Instruments DAQ hardware is to write register-level software. Writing register-level programming software can be very time-consuming and inefficient and is not recommended. Even if you are an experienced register-level programmer, consider using NI-DAQ, LabVIEW, or LabWindows/CVI to program your National Instruments DAQ hardware. -
Page 16: Optional Equipment
DAQCard-1200, store it in this envelope. Because the DAQCard-1200 is enclosed in a fully shielded case, no additional electrostatic precautions are necessary. However, for your own safety and to protect the DAQCard-1200, never attempt to touch the pins of the connectors. © National Instruments Corporation BNC-2081 CB-50 or CB-50LP I/O connector block with a 0.5 or 1.0 m cable... -
Page 17: Installation And Configuration
Notice that the card is keyed so that it can be inserted only one way. If your computer supports hot insertion, you may insert or remove the DAQCard-1200 at any time, whether your computer is powered on or off. -
Page 18: Configuration
Figure 2-1 shows an example of a typical configuration. Configuration The DAQCard-1200 is completely software configurable; refer to your software manuals to install and configure your software. If you are using NI-DAQ, refer to your NI-DAQ user manual or function reference manual. -
Page 19: Analog Input Configuration
Analog Input Polarity You can select the analog input on the DAQCard-1200 for either a unipolar range (0 to 10 V) or a bipolar range (–5 to +5 V). If you select a bipolar range, the two’s complement coding is selected. In this mode, –5 V input corresponds to F800 hex (–2,048 decimal) and +5 V corresponds to... -
Page 20: Analog Input Mode
RSE Input (Eight Channels, Default Setting) RSE input means that all input signals are referenced to a common ground point that is also tied to the DAQCard-1200 analog input ground. The RSE configuration is useful for measuring floating signal sources. See the of Signal Sources information. -
Page 21: Nrse Input (Eight Channels)
1, 3, 5, or 7 depending on which channel pair you select. Analog Output Configuration You can set the analog output on the DAQCard-1200 to either bipolar or unipolar configurations. Analog Output CH0 Polarity Analog Output CH1 Polarity ©... -
Page 22: Analog Output Polarity
Connections. Caution The DAQCard-1200 DIO lines are not pulled up or pulled down. If you are using these lines as digital outputs, add 10 k resistors to +5 V or DGND (depending on your application) to the DIO line(s) you are using. -
Page 23: Signal Connections
Warning Connections, including power signals to ground and vice versa, that exceed any of the maximum ratings of input or output signals on the DAQCard-1200 can damage the DAQCard-1200 and the PC. National Instruments is damages resulting from any such signal connections. -
Page 24: Figure 3-1. Daqcard-1200 I/O Connector Pin Assignments
37 38 39 40 EXTUPDATE* 41 42 OUTB0 43 44 OUTB1 45 46 CLKB1 47 48 GATB2 49 50 +5 V Figure 3-1. DAQCard-1200 I/O Connector Pin Assignments ACH1 ACH3 ACH5 ACH7 DAC0OUT DAC1OUT EXTTRIG EXTCONV* GATB0 GATB1 OUTB2 CLKB2 DGND ©... -
Page 25: Signal Connection Descriptions
Signal Connection Descriptions The following table describes the connector pins on the DAQCard-1200 front I/O connector by pin number and gives the signal name and the significance of each signal connector pin. Pins Signal Name Direction 1–8 ACH<0..7> AISENSE/AIGND DAC0OUT... -
Page 26: Analog Input Signal Connections
Pins 1 through 8 are analog input signal pins for the 12-bit ADC. Pin 9, AISENSE/AIGND, is an analog common signal. You can use this pin as a signal ground connection to the DAQCard-1200 in RSE mode, or as a return path in NRSE mode. Pin 11, AGND, is the bias current return point for differential measurements. -
Page 27: Figure 3-2. Daqcard-1200 Instrumentation Amplifier
How you connect analog input signals to the DAQCard-1200 depends on how you configure the card analog input circuitry and the type of input signal source. With different DAQCard-1200 configurations, you can use the instrumentation amplifier in different ways. Figure 3-2 shows a diagram of the DAQCard-1200 instrumentation amplifier. -
Page 28: Types Of Signal Sources
A/D conversions. All signals must be referenced to ground, either at the source device or at the DAQCard-1200. If you have a floating source, you must use a ground-referenced input connection at the DAQCard-1200. If you have a grounded source, you must use a nonreferenced input connection at the DAQCard-1200. -
Page 29: Input Configurations
Note If you power both the DAQCard-1200 and your PC with a floating power source, such as a battery, your system may be floating with respect to earth ground. In this case, treat all of your signal sources as floating sources. -
Page 30: Differential Connections For Grounded Signal Sources
Chapter 3 Signal Connections When you configure the DAQCard-1200 for DIFF input, each signal uses two of the multiplexer inputs—one for the signal and one for its reference signal. Therefore, only four analog input channels are available when using the DIFF configuration. You should use the DIFF input configuration when any of the following conditions is present: •... -
Page 31: Differential Connections For Floating Signal Sources
Front I/O Connector With this type of connection, the instrumentation amplifier rejects both the common-mode noise in the signal and the ground-potential difference between the signal source and the DAQCard-1200 ground, which is shown as V Differential Connections for Floating Signal Sources Figure 3-4 shows how to connect a floating signal source to a DAQCard-1200 that is configured for DIFF input. -
Page 32: Figure 3-4. Differential Input Connections For Floating Sources
DAQCard-1200 User Manual ACH 0 ACH 2 ACH 4 ACH 6 ACH 1 ACH 3 ACH 5 ACH 7 AGND DAQCard-1200 in DIFF Configuration Figure 3-4. Differential Input Connections for Floating Sources 3-10 Measured – Voltage – © National Instruments Corporation... -
Page 33: Single-Ended Connection Considerations
© National Instruments Corporation Input signals are high level (greater than 1 V). Leads connecting the signals to the DAQCard-1200 are less than 15 ft. All input signals share a common reference signal (at the source). section of Chapter 2,... -
Page 34: Single-Ended Connections For Grounded Signal Sources (Nrse Configuration)
On the other hand, if the input circuitry of the DAQCard-1200 is referenced to ground, such as in the RSE configuration, this difference in ground potentials appears as an error in the measured voltage. -
Page 35: Common-Mode Signal Rejection Considerations
Common-Mode Signal Rejection Considerations Figures 3-3 and 3-6 show connections for signal sources that are already referenced to some ground point with respect to the DAQCard-1200. In these cases, the instrumentation amplifier can reject any voltage caused by ground-potential differences between the signal source and the DAQCard-1200. -
Page 36: Analog Output Signal Connections
Figure 3-7 shows how to make analog output signal connections. VOUT 0 Load Load VOUT 1 Front I/O Connector DAQCard-1200 User Manual should remain within a range of –6 to +11 V in Output signal range Bipolar output ±5 V* –... -
Page 37: Digital I/O Signal Connections
Digital I/O Signal Connections Caution The DAQCard-1200 DIO lines are not pulled up or pulled down. If you are using these lines as digital outputs, add 10 k resistors to +5 V or DGND (depending on your application) to the DIO line(s) you are using. -
Page 38: Figure 3-8. Digital I/O Connections
TTL signals and sensing external device states such as the switch in Figure 3-8. Digital output applications include sending TTL signals and driving external devices such as the LED shown in Figure 3-8. DAQCard-1200 User Manual 22 PB0 TTL Signal... -
Page 39: Port C Pin Connections
Mode 2 Handshaking (Bidirectional Bus) *Indicates that the signal is active low. Subscripts A and B denote port A or port B handshaking signals. © National Instruments Corporation Table 3-3. Port C Signal Assignments Signal Assignments 3-17 Chapter 3 Signal Connections... -
Page 40: Timing Specifications
Acknowledge Input—A low signal on this handshaking line indicates that the data written from the specified port has been accepted. This signal is primarily a response from the external device that it has received the data from the DAQCard-1200. OBF* Output Output Buffer Full—A low signal on this handshaking line indicates... -
Page 41: Mode 1 Input Timing
Data after STB* = 1 RD* = 0 to INTR = 0 RD* = 1 to IBF = 0 All timing values are in nanoseconds. © National Instruments Corporation Minimum Figure 3-9. Mode 1 Timing Specifications for Input Transfers 3-19... -
Page 42: Mode 1 Output Timing
ACK* pulse width ACK* = 1 to INTR = 1 All timing values are in nanoseconds. Mode 2 Bidirectional Timing Figure 3-11 shows the timing specifications for bidirectional transfers in mode 2. DAQCard-1200 User Manual Minimum — — — —... -
Page 43: Figure 3-11. Mode 2 Timing Specifications For Bidirectional Transfers
ACK* = 0 to output ACK* = 1 to output float RD* = 1 to IBF = 0 All timing values are in nanoseconds. © National Instruments Corporation Figure 3-11. Mode 2 Timing Specifications for Bidirectional Transfers 3-21 Chapter 3... -
Page 44: Daq And General-Purpose Timing Signal Connections
DAQ and General-Purpose Timing Signal Connections Pins 38 through 48 of the front connector are connections for timing I/O signals. The DAQCard-1200 timing I/O uses two 82C53 counter/timer integrated circuits. One circuit, designated 82C53(A), is used exclusively for DAQ timing, and the other, 82C53(B), is available for general use. -
Page 45: Figure 3-13. Posttrigger Daq Timing
65,535. The number of samples acquired before the trigger is limited only by the size of the memory buffer available for data acquisition. © National Instruments Corporation t w 50 ns minimum t d 50 ns minimum Figure 3-13. -
Page 46: Figure 3-14. Pretrigger Daq Timing
OUTB1 enables an internal GATE signal that allows conversions to occur. The first conversion then occurs on the following falling edge of EXTCONV*. DAQCard-1200 User Manual t w 50 ns minimum Figure 3-14. Pretrigger DAQ Timing 3-24... -
Page 47: Figure 3-15. Interval-Scanning Signal Timing
DAC. When the EXTUPDATE* signal goes low, the DAC will subsequently be updated. Therefore, you can perform externally timed interrupt-driven waveform generation on the DAQCard-1200. Notice that the EXTUPDATE* signal is level sensitive; that is, if you perform writes to the DAC when EXTUPDATE* is low, the DAC is updated immediately. -
Page 48: General-Purpose Timing Signal Connections
For these applications, the CLK and GATE signals at the front I/O connector control the counters. The single exception is counter B0, DAQCard-1200 User Manual t w 50 ns min Figure 3-16. EXTUPDATE* Signal Timing for Updating DAC Output... -
Page 49: Figure 3-17. Event-Counting Application With External Switch Gating
2 MHz clock. Refer to the DAQCard-1200 Register-Level Programmer Manual for programming information. The GATE, CLK, and OUT signals for counters B1 and B2 are available at the I/O front connector. The GATE and CLK pins are internally pulled up to +5 V through a 100 k resistor. - Page 50 In this case, program the second counter for a one-slot mode. This configuration requires an external inverter to make the output pulse of the second counter active high. DAQCard-1200 User Manual 3-28 © National Instruments Corporation...
-
Page 51: Figure 3-18. Frequency Measurement Application
Chapter 3 Signal Connections +5 V 10 k GATE Signal Gate Counter Source Source DGND I/O Connector DAQCard-1200 Figure 3-18. Frequency Measurement Application © National Instruments Corporation 3-29 DAQCard-1200 User Manual... -
Page 52: Figure 3-19. General-Purpose Timing Signals
The GATE and OUT signals in Figure 3-19 are referenced to the rising edge of the CLK signal. DAQCard-1200 User Manual outg 380 ns min 230 ns min 150 ns min 100 ns min... -
Page 53: Power Connections
Power Connections Pin 49 of the I/O connector supplies +5 V from the DAQCard-1200 power supply. This pin is referenced to DGND. You can use the +5 V to power external digital circuitry. • Warning Do not directly connect this +5 V power pin to analog or digital ground or to any other voltage source on the DAQCard-1200 or any other device. -
Page 54: Theory Of Operation
FIFO Decode Circuitry, Core Logic 82C53 82C55A Ctr/Timer Digital Group A Interface 1MHz Timebase 2 MHz Time Timebase Divider 20 MHz Oscillator Figure 4-1. DAQCard-1200 Block Diagram Dither Input Gain Calibration 12-Bit 12-Bit 82C53 Ctr/Timer Group B DAQCard-1200 User Manual... -
Page 55: Pc Card I/O Channel Interface Circuitry
The PC Card I/O channel interface circuitry consists of an address bus, a data bus, interrupt lines, and several control and support signals. Figure 4-2 shows the components making up the DAQCard-1200 PC Card I/O channel interface circuitry. Address Bus... -
Page 56: Timing
I/O channel interface timing control circuitry, and interrupt control circuitry. Timing The DAQCard-1200 uses two 82C53 counter/timer integrated circuits for internal data acquisition and DAC timing and for general-purpose I/O timing functions. Figure 4-3 shows a block diagram of both groups of timing circuitry (counter groups A and B). -
Page 57: Figure 4-3. Timing Circuitry
Chapter 4 Theory of Operation GATEB2 CLKB2 OUTB2 GATEB1 CLKB1 OUTB1 OUTB0 GATEB0 2 MHz Source EXTCONV* EXTTRIG EXTUPDATE* DAQCard-1200 User Manual GATEB2 CLKB2 General- Purpose Counter OUTB2 OUTB0 GATEB1 CLKB1 Scan Interval/ General- Purpose Counter OUTB1 OUTB0 GATEB0 Timebase... -
Page 58: Analog Input
For a more detailed description of Counter Group A and Counters B0 and B1, refer to the following Analog Input and Analog Input The DAQCard-1200 has eight channels of analog input with software-programmable gain and 12-bit A/D conversion. The DAQCard-1200 also contains data acquisition timing circuitry for automatic timing of multiple A/D conversions and includes advanced options such as external triggering, gating, and clocking. -
Page 59: Analog Input Circuitry
±35 V powered on and ±25 V powered off. The mux counters control the input multiplexers. The DAQCard-1200 can perform either single-channel data acquisition or multiple-channel (scanned) data acquisition. These two modes are software selectable. - Page 60 Gaussian noise to the signal to be converted to the ADC. This addition is useful for applications involving averaging to increase the resolution of the DAQCard-1200 to more than 12 bits, as in calibration. In such applications, which are often lower frequency in nature, noise modulation is decreased and differential linearity is improved by the addition of the dither.
-
Page 61: Data Acquisition Timing
A/D conversions) is carefully timed. A data acquisition operation can either acquire a finite number of samples (controlled run) or an infinite number of samples (freerun). The DAQCard-1200 unit can perform both single-channel data acquisition and multiple-channel (scanned) data acquisition in two modes—continuous and interval. -
Page 62: Interval Data Acquisition
For single-channel scanning, this rate is limited only by the ADC conversion period plus the sample-and-hold acquisition time, which is specified at 10 s (11 s if EXTCONV* is used). © National Instruments Corporation Chapter 4 section in Chapter 3, Signal Connections. -
Page 63: Table 4-1. Analog Input Settling Time Versus Gain
10 s max 12 s typ, 15 s max 25 s typ, 30 s max 60 s typ, 80 s max Table 4-2. DAQCard-1200 Maximum Recommended Data Acquisition Rates Acquisition Mode Single channel 1, 2, 5, 10, 20, 50, 100... -
Page 64: Analog Output
Analog Output The DAQCard-1200 has two channels of 12-bit D/A output. Each analog output channel can provide unipolar or bipolar output. The DAQCard-1200 also contains timing circuitry for waveform generation timed either externally or internally. Figure 4-5 shows the analog output circuitry. -
Page 65: Power-On State
LSB write and an MSB write of the DAC in the immediate update mode, you will receive an incorrect value from that DAC until the MSB is written. Both of these effects are minimal at high waveform update rates. DAQCard-1200 User Manual 4-12 © National Instruments Corporation... -
Page 66: Digital I/O
(PPI) containing 24 programmable I/O pins. These pins represent the three 8-bit I/O ports (A, B, and C) of the 82C55A, as well as PA<0..7>, PB<0..7>, and PC<0..7> on the DAQCard-1200 I/O connector. Figure 4-6 shows the digital I/O circuitry. Decode Circuitry All three ports on the 82C55A are TTL-compatible. -
Page 67: Calibration
The lower half of the EEPROM contains user areas for calibration data. There are four different user areas. When the DAQCard-1200 is powered on, or when the conditions under which it is operating change, you must load the calibration DACs with the appropriate calibration constants. -
Page 68: Calibration At Higher Gains
Calibration Calibration at Higher Gains The DAQCard-1200 has a maximum gain error of 0.8%. This means that if the card is calibrated at a gain of 1, and if the gain is switched to 100, a maximum of 32 LSB error may result in the reading. Therefore, when you... - Page 69 RSE and for bipolar polarity, and you must configure the analog output circuitry for the correct polarity at which you want to perform output waveform generation. Refer to the NI-DAQ Function Reference Manual for PC Compatibles for more details on the function. Calibrate_1200 © National Instruments Corporation DAQCard-1200 User Manual...
- Page 70 Specifications This appendix lists the specifications for the DAQCard-1200. These specifications are typical at 25 °C unless otherwise noted. Analog Input Input Characteristics Number of channels ... 8 single-ended, Resolution ... 12 bits, 1 in 4,096 Max single-channel sampling rate ... 100 kS/s Input signal ranges Input coupling ...
- Page 71 Offset error Gain error (relative to calibration reference) Amplifier Characteristics Input impedance DAQCard-1200 User Manual Pre-gain error after calibration ...10 V max Pre-gain error before calibration ...±20 mV max Post-gain error after calibration...1 mV max Post-gain error before calibration...±200 mV max After calibration...0.02% of reading max...
- Page 72 Input offset current... ±100 pA CMRR ... 70 dB, DC to 60 Hz Dynamic Characteristics Bandwidth Settling time to full scale step System noise (not including quantization error) © National Instruments Corporation Small signal (–3 dB) Gain 1–10 Gain 1–10...
- Page 73 Offset error Gain error (relative to internal reference) If you perform simultaneous AI and AO, reliable continuous rates are limited to 0.5 to 1 kS/s and is configuration dependent. DAQCard-1200 User Manual Pre-gain...±15 V/°C Post-gain ...±100 V/°C After calibration...±0.5 mV max Before calibration ...±75 mV max...
- Page 74 Number of channels ... 24 I/O (three 8-bit ports; uses the Compatibility ... TTL Power-on state... All ports high impedance inputs © National Instruments Corporation 0 to 110 ms... +2 V to –5 V >110 ms... 0 V (±mV) Appendix A...
- Page 75 Timing I/O Number of channels...3 counters/timers Digital logic levels Input low voltage Input high voltage Output low voltage Output high voltage DAQCard-1200 User Manual Level = 2.5 mA) = –40 A) = –2.5 mA) Level = 4 mA) = –1 mA) –0.3 V...
-
Page 76: Appendix A Specifications
+5 VDC (±5%)... 150 mA operating, Physical Dimensions... 8.56 by 5.40 cm (3.37 by 2.13 in.) PC Card type ... Type II I/O connector... 50-pin male © National Instruments Corporation Counters/timers ... 16 bits Appendix A Specifications ±0.5 V powered off... - Page 77 Appendix A Specifications Environment Operating temperature ...0 to 50 °C Storage temperature ...–55 to 150 °C Relative humidity ...5% to 90% noncondensing DAQCard-1200 User Manual © National Instruments Corporation...
- Page 78 The DAQCard-1200 is register-compatible with the DAQPad-1200 (and the Lab-PC+) and functionally identical to it. Register-level software developed for the Lab-PC+ works directly on a configured DAQCard-1200. However, you calibrate the DAQCard-1200 with software instead of potentiometers. © National Instruments Corporation...
-
Page 79: Appendix B Differences Among The Lab-Pc+, The
Appendix B Differences among the Lab-PC+, the DAQPad-1200, and the DAQCard-1200 The following table summarizes the differences among the three products. Functionality Bus resource allocation Calibration Waveform generation FIFO size Maximum single-channel acquisition rate Power-management modes Fuse DAQCard-1200 User Manual... -
Page 80: Power-Management Modes
© National Instruments Corporation Normal Mode—This is the normal operating mode of the DAQCard-1200 in which all the circuits are fully functional. This mode draws about 150 mA from the 5 V supply (about 750 mW). Power-Down Mode—In this mode, the digital circuitry is powered on and is functional. - Page 81 Appendix C Power-Management Modes Table C-1. DAQCard-1200 Power-Management Modes (Continued) Normal Mode Calibration Functional. Both analog input and Circuitry analog output can be fully calibrated. The CALDACs default to 0 V. Digital I/O Functional. Defaults to high impedance inputs for all ports. Protected from –0.5 to 5.5 V.
-
Page 82: Pc Card Questions And Answers
PC Card system software configuration. Configuration Operation © National Instruments Corporation Do I need to use my PC Card configuration utility to configure the National Instruments PC Cards? No. We recommend that you do not configure our PC Cards using PC Card Control or an equivalent PC Card configuration utility. - Page 83 Appendix D PC Card Questions and Answers Resources DAQCard-1200 User Manual My computer locks up when I use a PC Card. What should I do? This usually happens because Card Services allocated an unusable interrupt level to the PC Card. For example, on some computers, interrupt level 11 is not routed to PC Cards.
- Page 84 © National Instruments Corporation are being used for ROM access, then you know that C8000–D3FFF is an invalid range for Card Services and should be changed to CA000–D3FFF. How can I find usable I/O addresses? Finding usable I/O addresses is done by trial and error. Of the three resources used—memory, I/O, interrupts—I/O conflicts will be...
-
Page 85: Resource Conflicts
Appendix D PC Card Questions and Answers Resource Conflicts DAQCard-1200 User Manual How do I resolve conflicts between my memory manager and Card Services? Card Services can usually use memory space that is not being used for real RAM on the system. Even when this is the case, you should still exclude the memory addresses used by Card Services from use by any memory manager that may be installed. -
Page 86: Technical Support Resources
Technical Support Resources This appendix describes the comprehensive resources available to you in the Technical Support section of the National Instruments Web site and provides technical support telephone numbers for you to use if you have trouble connecting to our Web site or if you do not have internet access. -
Page 87: Germany 089 741 31 30, Greece 30 1 42 96 427, Hong Kong 2645 3186, India
Web sites from If you have trouble connecting to our Web site, please contact your local National Instruments office or the source from which you purchased your National Instruments product(s) to obtain support. For telephone support in the United States, dial 512 795 8248. For... - Page 88 © National Instruments Corporation Value –12 –9 – 6 –3 DAQCard-1200 User Manual...
- Page 89 A/D and/or DIO boards plugged into a computer, and possibly generating control signals with D/A and/or DIO boards in the same computer direct current DGND digital ground signal DIFF differential configuration digital input signal DAQCard-1200 User Manual © National Instruments Corporation...
- Page 90 FIFO ahead of time. This again reduces the effect of latencies associated with getting the data from system memory to the DAQ device. GATE gate input signal © National Instruments Corporation DAQCard-1200 User Manual Glossary...
- Page 91 (signal) NRSE nonreferenced single-ended mode—all measurements are made with respect to a common (NRSE) measurement system reference, but the voltage at this reference can vary with respect to the measurement system ground DAQCard-1200 User Manual © National Instruments Corporation...
- Page 92 Signal Conditioning eXtensions for Instrumentation—the National Instruments product line for conditioning low-level signals within an external chassis near sensors so only high-level signals are sent to DAQ boards in the noisy PC environment transistor-transistor logic © National Instruments Corporation DAQCard-1200 User Manual Glossary...
- Page 93 (2) a LabVIEW software module (VI), which consists of a front panel user interface and a block diagram program volts, input high volts, input low volts in volts, output high volts, output low DAQCard-1200 User Manual © National Instruments Corporation...
- Page 94 (table), 4-10 data acquisition timing, 4-8 to 4-9 continuous data acquisition, 4-8 data acquisition operation, 4-8 interval data acquisition, 4-9 © National Instruments Corporation polarity configuration, 2-3 settings (table), 2-3 power-management modes (table), C-1 specifications, A-1 to A-4...
- Page 95 A-5 output characteristics, A-4 stability, A-5 transfer characteristics, A-4 voltage output, A-5 theory of operation, 4-11 to 4-12 DAQCard-1200 User Manual bus interface specifications, A-7 calibration, 5-1 to 5-3 EEPROM storage, 5-1 equipment requirements, 5-2 higher gains, 5-2...
- Page 96 1-4 theory of operation. See theory of operation. unpacking, 1-5 DAQPad-1200, compared with Lab-PC+ and DAQCard-1200, B-1 to B-2 data acquisition rates, 4-9 to 4-10 maximum recommended rates (table), 4-10 settling time vs. gain (table), 4-10 data acquisition timing circuitry, 4-8 to 4-9 continuous data acquisition, 4-8 ©...
- Page 97 1 input timing, 3-19 mode 1 output timing, 3-20 mode 2 bidirectional timing, 3-20 to 3-21 documentation conventions used in manual, x National Instruments documentation, xi organization of manual, ix-x related documentation, xii dynamic characteristics analog input specifications, A-3 analog output specifications, A-5...
- Page 98 1 input timing, 3-19 mode 1 output timing, 3-20 mode 2 bidirectional timing, 3-20 to 3-21 © National Instruments Corporation National Instruments Web support, E-1 to E-2 NI-DAQ driver software, 1-3 to 1-4 NRSE input configuration, 2-5 definition (table), 2-4...
- Page 99 (figure), 3-24 pretrigger mode, 3-23 problem-solving and diagnostic resources, online, E-1 pulse generation, 3-27 pulsewidth measurement, 3-28 DAQCard-1200 User Manual RD* signal (table), 3-18 referenced single-ended mode. See RSE input. register-level programming, 1-4 requirements for getting started, 1-2 RSE input...
- Page 100 (RSE configuration), 3-11 to 3-12 ground-referenced signal sources (NRSE configuration), 3-12 to 3-13 when to use, 3-11 © National Instruments Corporation software programming choices, 1-2 to 1-4 LabVIEW and LabWindows/CVI, 1-3 NI-DAQ driver software, 1-3 to 1-4 register-level programming, 1-4...
- Page 101 Index analog output, 4-11 to 4-12 circuitry, 4-11 DAC timing, 4-12 power-on state, 4-12 block diagram of DAQCard-1200, 4-1 digital I/O, 4-13 functional overview, 4-1 to 4-2 PC card I/O channel interface circuitry, 4-2 to 4-3 timing, 4-3 to 4-5...
