3
Remove the three screws, and then remove the motor.
2 x 500-sheet tray controller board removal
1
Remove the rear cover. See
2
Disconnect all the cables from the board.
#
1
Motor (2 x 500‑sheet tray 3 feed)
2
Motor (2 x 500‑sheet tray 4 feed)
3
Motor (2 x 500‑sheet tray 4 transport)
4
Motor (2 x 500‑sheet tray 3 transport)
"2 x 500-sheet tray rear cover removal" on page
Repair information
374
Part
370.
4021
