Motor (feed) removal

1
Remove the port access door. See
2
Remove the controller board access cover. See
3
Remove the engine board cover. See
4
Remove the scanner interface cable cover. See
5
Remove the upper rear cover. See
6
Open the controller board frame. See
7
Disconnect the cable (A), remove the two screws (B), and then remove the bracket.
"Port access door removal" on page
"Controller board access cover removal" on page
"Engine board cover removal" on page
"Scanner interface cable cover removal" on page
"Upper rear cover removal" on page
"Controller board frame removal" on page
Repair information
312
228.
289.
289.
305.
4021
287.
286.
