Lexmark MS911 Service Manual page 152

2 x 500‑sheet tray 4 lift plate failure service check
Action
Step 1
Enter the Diagnostics menu, and then navigate to:
PRINTER SETUP > Reset Engine Service Error
Does the problem remain?
Step 2
Enter the Diagnostics menu, and then navigate to:
MOTOR TESTS > 2 x 500-Sheet Tray Motor Tests > Tray 4 lift
Does the motor run?
Step 3
a
Reseat the motor cable.
b
Check the cable for damage, and replace if necessary.
Does the problem remain?
Step 4
Replace the motor. See "Motor (2 x 500-sheet tray lift) removal" on
page 370.
Does the problem remain?
Step 5
a
Make sure that the tray 4 tray set actuator is properly installed.
b
Check the actuator for damage, and replace if necessary.
500‑sheet tray tray set actuator removal" on page
Does the problem remain?
Step 6
Check the sensor (2 x 500-sheet tray 4 lift plate level).
Is it free of damage?
Step 7
Enter the Diagnostics menu, and then navigate to:
SENSOR TESTS > 2 x 500-Sheet Tray Sensor Tests > Tray 4 lift plate limit
Does the sensor status change while toggling the sensor?
Step 8
a
Reseat the sensor cable.
b
Check the cable for damage, and replace if necessary.
Does the problem remain?
Yes
Go to step 2.
Go to step 5.
Go to step 4.
Go to step 5.
Go to step 6.
"2 x
380.
Go to step 7.
Go to step 10.
Go to step 9.
Diagnostic information
152
4021
No
The problem is solved.
Go to step 3.
The problem is solved.
The problem is solved.
The problem is solved.
Go to step 9.
Go to step 8.
The problem is solved.
