Tray 2 Transport Drive Removal - Lexmark MS911 Service Manual

8
Remove the two screws (C), and then remove the motor.

Tray 2 transport drive removal

1
Remove the port access door. See
2
Remove the controller board access cover. See
3
Remove the engine board cover. See
4
Remove the scanner interface cable cover. See
5
Remove the upper rear cover. See
6
Open the controller board frame. See
"Port access door removal" on page
"Controller board access cover removal" on page
"Engine board cover removal" on page
"Scanner interface cable cover removal" on page
"Upper rear cover removal" on page
"Controller board frame removal" on page
Repair information
313
228.
289.
289.
305.
4021
287.
286.
