Property
TCP/IP (Ethernet)
IP Addressing
Gateway
Subnet Mask
Primary WINS
Microsoft Device
Name
Microsoft Workgroup
IPX/SPX (Ethernet
only)
ipc1-im8130 Administrator's Guide
Analyze the default ipc1-im8130 Network Settings
The following table summarizes the default controller settings. To
adjust these settings locally use the copier's control panel To
adjust them remotely, use Printer Utility.
Default Controller Settings
Default Setting
Enabled
DHCP
[blank]
255.0.0.0
[blank]
ipc1<MAC Address>
WORKGROUP
Auto Sense
Comments
Frame Type set to Ethernet II.
If you don't want to take advantage of
your network's DHCP services, change
IP Addressing to Manual and enter the
IP Address either locally or remotely.
Specify the Gateway address if TCP/IP
is enabled and IP Addressing is set to
Manual. Otherwise, use DHCP to set
the Gateway address.
Specify the Subnet Mask address if
TCP/IP is enabled and IP Addressing is
set to Manual. Otherwise, use DHCP to
set the Subnet Mask address.
DHCP can be used to set the primary
WINS address.
<MAC Address> is the unique media
access control address of the NIC
installed on the ipc1-im8130. The
Microsoft Device Name is mandatory
as it is used for both Microsoft and
Macintosh printing.
The Microsoft Workgroup Name is
mandatory for Microsoft printing.
Additionally, it is required if you want to
update the controller software using
Printer Utility.
The ipc1-im8130 attempts to
automatically sense the IPX frame type.
This facilitates automatic device
discovery. However, if you are running
a TCP/IP-only network, you should
disable IPX/SPX to eliminate
unnecessary network traffic.
