imagistics ipc1-im8130 Administrator's Manual page 160

160
NDPS Printer Agent. The following figure illustrates the
communication flow between these objects.
Communication flow
Note: While this diagram illustrates the NDPS Gateway,
Broker/Manager and Printer Agent as distinct objects, they
are actually all NLM applications residing on the NetWare
file server.
1 The NetWare printer can be discovered in two ways:
The printer is automatically discovered by the Imagistics
NDPS Gateway.
You add it manually to the NDPS Manager, which resides
on the same NetWare file server as the Imagistics NDPS
Gateway.
2 When an end-user attempts to add a NDPS printer, the client
queries the NDPS Brokers to identify all available NDPS
printers.
3 The NDPS Broker responds with a list of NDPS Printer
Agents. The user selects a Printer Agent and the Imagistics
NDPS Gateway downloads the appropriate driver to the
user's desktop.
ipc1-im8130 Administrator's Guide
