114
Configuring Ethernet NIC Speed
1
On the Administration tab, click the
2
Click the
Network
The Network page opens.
3
In the Ethernet area, click the Speed drop-down list.
4
Select the appropriate speed for the controller's NIC.
The default setting is Auto, which automatically senses and
sets the correct speed.
5
Click
.
Save
6
Follow the instructions in
Settings
on page 113.
Configuring IPX/SPX Settings
1
On the Administration tab, click the
2
Click the
Network
The Network page opens.
3
In the IPX/SPX area, click the Protocol drop-down list.
4
Select
to enable IPX/SPX.
Enable
This is the default setting.
5
Click the Frame Type drop-down list.
6
Select the appropriate setting.
The default setting is Auto.
7
Click
.
Save
8
Follow the instructions in
Settings
on page 113.
Configuring TCP/IP Settings
1
On the Administration tab, click the
2
Click the
Network
The Network page opens.
3
In the TCP/IP area, click the IP Address Resolution drop-
down list.
4
Select either
Static IP
Setup
link.
Applying Changes to Protocol
Setup
link.
Applying Changes to Protocol
Setup
link.
or
.
DHCP
ipc1-im8130 Administrator's Guide
subtab.
subtab.
subtab.
