imagistics ipc1-im8130 Administrator's Manual page 355

Term
Current Jobs
Data Rate
Data Retries
Default Access Point
(DAP)
Department folder
Device
DHCP
DIN
DNS server
Document
Identification Number
(DIN)
Document editor /
organizer
Document Profile
ipc1-im8130 Operator's Guide (Basic)
Definition of Common Terms
The list of all print and copy jobs currently queued to the selected
ipc1-im8130 controller. You can view it using either the Printer
Utility or the ipc1 Document Monitor application.
In wireless networking, the rate at which data packets are
transmitted to or received from the access point.
Defines the number of times a data packet will be resent if the
initial transmission is unsuccessful.
In wireless networking, the MAC address of the access point to
which the client should connect if possible (if the client and the
DAP have the same SSID)
A Document Manager system folder. The administrator can store
and work with documents in the Department folder. Registered
and unregistered users can view and print documents in the
Department folder, but cannot edit them.
Refers to the ipc1-im8130 controller connected to a network
digital copier. Often, the term device is used to refer to the entire
controller/copier system.
Dynamic Host Configuration Protocol. A TCP/IP protocol which
enables a network connected to the Internet to assign a
temporary IP address automatically to a host computer that
connects to the network.
Document Identification Number. You must enter this number at
the copier to release private jobs for printing.
Domain Name System server. An Internet server that translates
host names into numeric IP addresses.
The 5-digit code required to release a Private Print job for printing.
Enter the DIN from the copier's control panel.
Refers to the Document Manager application, which enables you
to store, edit, manage and print scanned images using a web
interface.
A pre-defined set of driver settings that allows you to auto-
configure your print job with a click of the mouse.
Definition
125
