5 In the Device Name field, enter the controller name.
6 Enter the controller's Workgroup.
7 Enter the address of the Primary WINS Server.
8 Enter a WINS Scope ID for the controller.
9 To set the controller as a master browser, click the
drop-down list and select
Browser
10 Click .
Save

Configuring AppleTalk Settings

1 On the Administration tab, click the
2 Click the
Wi-Fi Network
The Wi-Fi Network page opens.
3 In the AppleTalk area, click the
4 Select to enable AppleTalk.
Enable
5 Enter the AppleTalk Zone string.
.
6 Click
Save

Configuring the Wi-Fi NIC Settings

1 On the Administration tab, click the
2 Click the
Wi-Fi Network
The Wi-Fi Network page opens.
3 In the General area, enter the controller's SSID.
4 Select the Network Type from the drop-down list.
5 If required, check
The WEP Encryption, WEP Key and Authentication fields
are enabled.
6 Select the type of WEP Encryption from the drop-down list
box.
7 Enter the WEP Key as 5 or 13 sets of hex characters.
8 Select the Authentication mode from the drop-down list box.
9 Enter the identifier of the Default Access Point as 6 sets of
hex characters (Infrastructure network type only).
10 Enter the Channel number (Ad Hoc network type only).
Enable
Setup
link.
Protocol
Setup
link.
and
Use WEP Security
Master
.
subtab.
drop-down list.
subtab.
.
Set WEP key
119
