REP 9.5 Toner Cartridge Guide
Parts List on
PL 8.2
Removal
1.
To remove the Toner Cartridge Guide go to
Replacement
1.
To reinstall, carry out the removal steps in reverse order.
Initial Issue
WorkCentre 5335 Family Service Documentation
REP 6.2
ROS Assembly Steps 1 through 8.
BUS Updated 12/2011
REP 9.6 Toner Dispense Motor
Parts List on
PL 8.2
Removal
1.
Switch off the power and disconnect the power cord.
2.
Perform the following
(Figure
1).
a.
Open the Front Cover and the Left Hand Cover.
b.
Remove the Xerographic Cartridge and the Toner Cartridge.
a
07/2011
4-77
b
Figure 1 Removals
Repairs & Adjustments
REP 9.5, REP 9.6
